Ultra-Precision Cutting of Single Crystal Silicon Using Diamond Tool with Large Top Corner Radius

Abstract:

A lot of studies on the ultra-precision cutting of single crystal silicon have been reported and they used the single crystal diamond cutting tools having the sharp cutting edge. However, the diamond cutting tools having small chamfer at the cutting edge are usually used in practical machining shops. In addition, studies on the relationship between the tool wear and the machined surface have been reported little although the relationship is important in practical applications. In this study, ultra-precision cutting of single crystal silicon, using cutting fluids, feed rate, and depth of cut as experimental parameters, were carried out by using the single crystal diamond cutting tools having small chamfer and large nose radius, and effects of the cutting fluids, the feed rate, and the depth of cut on the machining accuracy and tool wear were studied. As a result, the optimum cutting conditions was obtained as follows: the cutting fluid was kerosene, the feed rate was 2.0μm/rev, and the depth of cut was 1.0μm.

• Periodical: Key Engineering Materials (Volumes 523-524)
• Pages: 81-86
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.523-524.81
• Online since: November 2012
• Authors: Yuya Kobaru, Eiji Kondo, Ryuichi Iwamoto
• Keywords: Cutting Fluid, Large Top Corner Radius Tool, Single Crystal Silicon, Ultra-Precision Cutting

References

[1] H. Huang, BL. Wang, Y. Wang, J. Zou and L. Zhou. Materials Science and Engneering A. 479, 1-2 (2008) 373-379

[2] W.K. Chen, T. Kuriyagawa, H. Huang and N. Yosihara. Journal of the International Societies for Precision Engineering. 29, 3 (2005) 315-323

[3] J. Yan, K. Syoji, H. Suzuki and T. Kuriyagawa. Japan Society for Precision Engineering. 64, 9 (1998) 1345-1349 (in Japanese)

[4] J. Yan, K. Syoji and T. Kuriyagawa. Japan Society for Precision Engineering. 66, 7 (2000) 1130-1134 (in Japanese)

[5] T. Ota, J. Yan, S. Kodera, S.Yajima, Y. Takahashi, N. Horikawa and T. Kuriyagawa. Japan Society for Abrasive Technology. 52, 11 (2008) 651-656 (in Japanese)

[6] T. Shibata, S. Fujii, A. Fujii, E. Makino and M. Ikeda. Japan Society for Precision Engineering. 62, 11 (1996) 1632-1637 (in Japanese)

[7] Information on http://www.allied-material.co.jp/products/diamond/cutting/upc2/

[8] Y. Ichida, N. B. Frej and R. Yousefi. Japan Society for Precision Engineering. 64, 4 (1998) 608-612 (in Japanese)
