Uniform Cooling and Part Warpage Reduction in Injection Molding Thanks to the Design of an Effective Cooling System

Abstract:

In this paper, a new methodology for the design of effective cooling system of thermoplastic injection tools is proposed. It is named MCOOL® for Morpho Cooling. It allows the design of the cooling channels in the mold with no a priori on the number, the size, the shape of the channels and the temperature of the coolant before performing the optimization. Numerical and experimental results obtained on a mold manufactured thanks to this methodology are compared with those coming from a conventional design. The criteria used to discriminate the results are based on the uniformity of the temperature field in the molded part and on the final warpage of the part.

• Periodical: Key Engineering Materials (Volumes 554-557)
• Pages: 1611-1618
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.554-557.1611
• Online since: June 2013
• Authors: Alban Agazzi, Vincent Sobotka, Ronan Le Goff, Yvon Jarny
• Keywords: Conformal Cooling, Cooling Channels, Cooling System Design, Injection Molding Process, Optimization

References

[1] R. Sanchez, J. Aisa, A. Martinez, D. Mercado, On the relationship between cooling setup and warpage in injection molding, Measurement, 45(2012) 1051-1056

DOI: 10.1016/j.measurement.2012.01.039

[2] H. Hassan,N. Regnier, C. Pujos, E. Arquis, G. Defaye, Modeling the effect of cooling system on the shrinkage and temperature of the polymer by injection molding, Applied Thermal Engineering, 30(2010) 1547-1557

DOI: 10.1016/j.applthermaleng.2010.02.025

[3] Y. C. Lam, L. Y. Zhai, K. Tai, and S. C. Fok, An evolutionary approach for cooling system optimization in plastic injection moulding, International Journal of Production Research, 42(2004) 2047-2061

DOI: 10.1080/00207540310001622412

[4] H. Qiao, A systematic computer-aided approach to cooling system optimal design in plastic injection molding, International Journal of Mechanical Sciences, 48(2006) 430-439

DOI: 10.1016/j.ijmecsci.2005.11.001

[5] L. Tang, K. Pochiraju, C. Chassapis, and S. Manoochehri, A computer-aided optimization approach for the design of injection mold cooling systems, Journal of Mechanical Design, 120(1998) 165-174

DOI: 10.1115/1.2826955

[6] E. Mathey, L. Penazzi, F. Schmidt, and F. Rond-Oustau, Automatic optimization of the cooling of injection mold based on the boundary element method, Materials processing and design: Modeling, Simulation and Applications-NUMIFORM-Proceeding of the 8th International Conference on Numerical Methods in Industrial Forming Process, vol. 712, no. 1, pp.222-227, Colombus, Ohio, USA, 2004.

DOI: 10.1063/1.1766527

[7] A. Agazzi, V. Sobotka, R. Le Goff, D. Garcia, and Y. Jarny, Method for forming channels in a tool, tool thus formed and computer program product that performs such a method, Patent, WO 2012/168669 A2

[8] A. Agazzi, V. Sobotka, R. Le Goff and Y. Jarny, Optimal cooling design in injection moulding process- A new approach based on morphological surfaces, Applied Thermal Engineering, 52(2013) 170-178

DOI: 10.1016/j.applthermaleng.2012.11.019

[9] J. Serra, Image analysis and mathematical morphology, Academic Press, London, UK, (1982)

[10] R. Fletcher and C. M. Reeves, Functions minimization by conjugate gradients, The Computer Journal, 7(1964) 149-154.

[11] Woodbury K. A., "Inverse Engineering Handbook-The Adjoint Method to compute the Numerical Solutions of Inverse Problems-Jarny, Y., C. press LLC, Ed. 2003.

DOI: 10.1201/9781420041613.ch3

[12] O. Schenk and K. Gärtner, On fast factorization pivoting methods for symmetric indefinite systems, Elec. Trans. Numer. Anal, 23(2006). 158–179.
