3D Simulation of Laser Assisted Side Milling of Ti6Al4V Alloy Using Modified Johnson-Cook Material Model

Abstract:

During machining of hard materials, one approach to reduce tool wear is using a laser beam to preheat the material in front of the cutting zone. In this study, a new concept of laser-assisted milling with spindle and tool integrated laser beam guiding has been tested. The laser beam is located at the cutting edge and moving synchronously with the cutter. In experiment, a reduction in the resulting process cutting forces and tool wear has been observed in comparison to milling without laser. A three-dimensional finite element model in DEFORM 3D was developed to predict the cutting forces in the milling process with and without an additional laser heat source, based on a Johnson-Cook-type material constitutive model adapted for high strains and strain rates. Both in experiment and simulation, the deformation behavior of a Ti-6Al-4V workpiece has been investigated. The comparison of the resulting cutting forces showed very good agreement. Thus the new model has great potential to further optimize laser assisted machining processes.

• Periodical: Key Engineering Materials (Volumes 554-557)
• Pages: 2054-2061
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.554-557.2054
• Online since: June 2013
• Authors: Hassan Zamani, Jan Patrick Hermani, Bernhard Sonderegger, Christof Sommitsch
• Keywords: Cutting Force, Finite Element Method (FEM), Laser Assisted Machining, Side Milling, Ti6Al4V

References

[1] W. König, A. Zaboklicki, Laserunterstützte Drehbearbeitung von Silizium-Nitrid-Keramik, VDI-Z 135, 6 (1993), 34-39.

[2] E. O. Ezugwu, Z. M. Wang, Titanium alloys and their machinability—a review, Journal of Materials Processing Technology, 68 (1997), 262–274.

DOI: 10.1016/s0924-0136(96)00030-1

[3] C. Brecher, M. Emonts, C. J. Rosen and J. P. Hermani, Laser-assisted Milling of Advanced Materials, Physics Procedia, 12 (2011), 599-606.

DOI: 10.1016/j.phpro.2011.03.076

[4] K. C. Mills, Recommended Values of Thermo physical Properties for Selected Commercial Alloys, Woodhead Publishing (2002), 217.

[5] Deform-User Manual SFTC-Deform V10.0.2, Columbus (OH), USA, (2010).

[6] N. Zorev, Inter-relationship between shear processes occurring along tool face and shear plane in metal cutting, International Research in Production Engineering, 1963, 42-49.

[7] M. Calamaz, D. Coupard, F. Girot, A New Material Model for 2D Numerical Simulation of Serrated Chip Formation when Machining Titanium Alloy Ti–6Al–4V, International Journal of Machine Tools & Manufacture,48 (2008), 275–288.

DOI: 10.1016/j.ijmachtools.2007.10.014

[8] M. Sima, T. Özel, Modified material constitutive models for serrated chip formation simulations and experimental validation in machining of titanium alloy Ti6Al4V, International Journal of Machine Tools and Manufacture 50 (2010), 943-960.

DOI: 10.1016/j.ijmachtools.2010.08.004

[9] D. Ulutan, M. Sima, T. Özel, Prediction of Machining Induced Surface Integrity using Elastic-Viscoplastic Simulations and Temperature-Dependent Flow Softening Material Models in Titanium and Nickel-based alloys, Advanced Materials Research, 223(2011), 401-410.

DOI: 10.4028/www.scientific.net/amr.223.401
