Vision-Based Sensing in Dynamic Tests

Abstract:

The availability of a suitable data acquisition sensor network is a key implementation issue to link models with real world structures. Non-contact displacement sensors should be preferred since they do not change the system properties. A two-dimensional vision-based displacement measurement sensor is the focus of this contribution. In particular, the perspective distortion introduced by the angle between the optic axis of the camera and the normal to the plane in which the structural system deforms is considered. A two-dimensional affine transformation is utilized to eliminate the distortion from the recorded to the distortion-free image. The results of a laboratory experiment show the potential of the proposed approach.

• Periodical: Key Engineering Materials (Volumes 569-570)
• Pages: 767-774
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.569-570.767
• Online since: July 2013
• Authors: Fabio Casciati, Sara Casciati, Li Jun Wu
• Keywords: Damage Assessment, Structural Health Monitoring (SHM), Structural Integrity, System Identification

References

[1] Casciati, F. and L. J. Wu. Wireless links for global positioning system receivers. Smart Structure and Systems. 10 (1) (2012) 1-14.

DOI: 10.12989/sss.2012.10.1.001

[2] Casciati, F. and L. J. Wu. Local Positioning Accuracy of Laser Sensors for Structural Health Monitoring, Structural Control and Health Monitoring, 20 (5) (2013) 728-739.

DOI: 10.1002/stc.1488

[3] Jurjo D.L.B. R, Magluta C., Roitman N. and Gonçalves P.B. Identification of Structural Nonlinear Dynamic Behavior of Flexible Metallic Columns under the Action of Self-weight, Mecánica Computacional, Volume XXIX. Number 92. Identification and Reliability of Structures (B) (2010).

[4] Jurjo, D. L. B. R., C. Magluta, et al. Experimental methodology for the dynamic analysis of slender structures based on digital image processing techniques. Mechanical Systems and Signal Processing, 24(5) (2010) 1369-1382.

DOI: 10.1016/j.ymssp.2009.12.006

[5] Uhl, T., P. Kohut, et al. Vision based condition assessment of structures. Journal of Physics: Conference Series 305: 012043 (2011).

DOI: 10.1088/1742-6596/305/1/012043

[6] Olaszek, P. Investigation of the dynamic characteristic of bridge structures using a computer vision method. Measurement 25 (1999) 227–236.

DOI: 10.1016/s0263-2241(99)00006-8

[7] Lee, J. and M. Shinozuka. Real-Time Displacement Measurement of a Flexible Bridge Using Digital Image Processing Techniques. Experimental Mechanics 46(1) (2006) 105-114.

DOI: 10.1007/s11340-006-6124-2

[8] Zitová, B. and J. Flusser. Image registration methods: a survey. Image and Vision Computing 21(11) (2003) 977-1000.

DOI: 10.1016/s0262-8856(03)00137-9

[9] Ashburner, J. Image Registration. (2012) from http: /www. slideserve. com/boyce/ image-registration-john-ashburner.

[10] Casciati, F. and L. J. Wu. Structural Monitoring Through Acquisition of Images. The International Conference Model Based Control of Structures and Machines. St. Petersburg (2012).

[11] Casciati, F. and L. J. Wu. A Non Contact Displacement Measurement System based on Vision System. The International Symposium on Innovation & Sustainability of Structures in Civil Engineering. XiaMen, China (2011).
