Interpolation Damage Detection Method on a Suspension Bridge Model: Influence of Sensors Disturbances

Abstract:

In this paper the IDDM (Interpolation Damage Detection Method), recently proposed as a speedy damage detection and localization technique, is applied to the numerical model of a cable suspended bridge derived from the ANSYS model of the Shimotsui-Seto Bridge in Japan (940m length of the main span). The wind excitation is simulated as a spatially correlated process acting in the horizontal direction, transversal to the deck. The bridge is assumed to be monitored by sensors located at the nodes of the model along the longitudinal axis, and recording the absolute acceleration of the bridge deck in the transversal direction Noise in recorded responses can reduce the sensitivity of the method to damage. The influence of noise on the results of the damage detection method is herein investigated by adding a white-noise signal to the structural responses. The mutual relationship between level of noise, intensity of damage and lengths of recorded signals is also investigated with reference to various damage scenarios.

• Periodical: Key Engineering Materials (Volumes 569-570)
• Pages: 734-741
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.569-570.734
• Online since: July 2013
• Authors: Marco Domaneschi, Maria Pina Limongelli, Luca Martinelli
• Keywords: Damage Detection, IDDM, Long-Span Bridges, Noise

References

[1] M.P. Limongelli, Frequency Response Function Interpolation for Damage Detection under Chang-ing Environment, Mechanical Systems and Signal Processing. 24 (2010) 2898-2913.

DOI: 10.1016/j.ymssp.2010.03.004

[2] M.P. Limongelli, The interpolation damage detection method for frames under seismic excitation, Journal of Sound and Vibration. 330 (2011) 5474–5489.

DOI: 10.1016/j.jsv.2011.06.012

[3] M. Domaneschi, M.P. Limongelli, L. Martinelli, Wind Driven Damage Detection on a Suspended Bridge, Experimental Vibration Analysis for Civil Engineering Structures - EVACES 2011. Varenna I (2011). ISBN 978-88-96225-39-4.

[4] A.K. Pandey, M. Biswas, M.M. Samman, Damage Detection from Changes in Curvature Mode Shapes, Journal of Sound and Vibration. 145 (1991) 321–332.

DOI: 10.1016/0022-460x(91)90595-b

[5] C.P. Ratcliffe, A frequency and curvature based experimental method for locating damage in structures, Transactions of the American Society of Mechanical Engineers Journal of Vibration and Acoustics. 122 (2000) 324–329.

DOI: 10.1115/1.1303121

[6] S. Casciati, M. Domaneschi, D. Inaudi, Damage assessment from SOFO dynamic measurements, Proceedings of SPIE - The International Society for Optical Engineering. 5855 (2005) 1048-1051. ISSN: 0277786X.

DOI: 10.1117/12.623656

[7] S. Casciati, M. Domaneschi, D. Inaudi, Local damage detection from dynamic SOFO experimental data, Proceedings of SPIE - The International Society for Optical Engineering. 5765 (2005) 591-599. ISSN: 0277786X.

DOI: 10.1117/12.623656

[8] R.J. Allemang, D.L. Brown, A Correlation Coefficient for Modal Vector Analysis, Proc. 1st Inter-national Modal Analysis Conference (IMAC). (1982) 110-116.

[9] M. Domaneschi, L. Martinelli, Optimal Passive and Semi-active Control of a Wind Excited Suspension Bridge, Structure and Infrastructure Engineering. 9 (2013), 242-259.

DOI: 10.1080/15732479.2010.542467
