Sensing Properties of YSZ-Based NO Sensors with Double-Perovskite (La_0.8Sr_0.2)₂FeNiO_6-δ Sensing Electrodes

Abstract:

The powder of (La_0.8Sr_0.2)₂FeNiO_6-δ (LSFN) oxide with double-perovskite structure was synthesized by polymeric precursor method. Then the YSZ-based NO sensors with LSFN sintered at different temperatures (1000, 1100, 1200 and 1300 °C) as sensitive electrode (SE) were fabricated. All samples were characterized by XRD. The morphologies of the LSFN-SEs were observed with ESEM. The NO sensing properties of the sensors were investigated in the operating temperature range of 350-650 °C in 10 vol. % O₂. Results demonstrated that the sensor with LSFN-SE sintered at 1300 °C exhibited highest response to 500 ppm NO at 400 °C, which was about 85 mV. A linear relationship was obtained between the emf and the logarithm of NO concentration from 500 to 800 ppm at 400 and 500 °C. Moreover, both magnitude and slope to NO response decreased as operating temperature increased. And both the response time and recovery time shortened as temperature increased. But the recovery rate was slower than the response rate, especially at and below 450 °C. The optimal sensor response was obtained at 500-550 °C.

• Periodical: Key Engineering Materials (Volumes 602-603)
• Pages: 845-850
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.602-603.845
• Online since: March 2014
• Authors: Li Hong Zhou, Hai Yan Wu, Quan Yuan, Xiang Dong Li, Pei Wei Xu, Rong Wang, Feng Xia, Jian Zhong Xiao*
• Keywords: (La_0.8Sr_0.2)₂FeNiO_6-δ, Double Perovskite, NO_x Sensor, Polymeric Precursor Method

References

[1] S. Zhuiykov, N. Miura, Development of zirconia-based potentiometric NOx sensors for automotive and energy industries in the early 21st century: What are the prospects for sensors? Sens. Actuators B 121 (2007) 639-651.

DOI: 10.1016/j.snb.2006.03.044

[2] B.G. Nair, J. Nachlas and M. Middlemas, U.S. Patent 7, 217, 355. (2007).

[3] N. Miura, M. Nakatou, S. Zhuiykov, Impedance-based total-NOx sensor using stabilized zirconia and ZnCr2O4 sensing electrode operating at high temperature, Electrochem. Commun. 4 (2002) 284-287.

DOI: 10.1016/s1388-2481(02)00266-7

[4] V.V. Plashnitsa, P. Elumalai, Y. Fujio, N. Miura, Zirconia-based electrochemical gas sensors using nano-structured sensing materials aiming at detection of automotive exhausts, Electrochim. Acta 54 (2009) 6099-6106.

DOI: 10.1016/j.electacta.2008.12.040

[5] C. López-Gándara, J. M. Fernández-Sanjuán, F.M. Ramos, A. Cirera, Role of nanostructured WO3 in ion-conducting sensors for the detection of NOx in exhaust gases from lean combustion engines, Solid State Ion. 184 (2011) 83-87.

DOI: 10.1016/j.ssi.2010.09.003

[6] J. Parka, B.Y. Yoon, C.O. Park, W. Lee, C.B. Lee, Sensing behavior and mechanism of mixed potential NOx sensors using NiO, NiO (+YSZ) and CuO oxide electrodes, Sens. Actuators B 135 (2009) 516-523.

DOI: 10.1016/j.snb.2008.10.006

[7] F.M. Van Assche, J.C. Nino, E.D. Wachsman, Infrared and X-ray photoemission spectroscopy of adsorbates on La2CuO4 to determine potentiometric NOx sensor response mechanism, J. Electrochem. Soc. 155 (2008) J198-J204.

DOI: 10.1149/1.2912741

[8] E.N. Armstrong, T. Striker, V. Ramaswamy, J.A. Ruud, E.D. Wachsman, NOx adsorption behavior of LaFeO3 and LaMnO3+δ and its influence on potentiometric sensor response, Sens. Actuators B 158 (2011) 159-170.

DOI: 10.1016/j.snb.2011.05.060

[9] J. Wang, P. Elumalai, D. Terada, M. Hasei, N. Miura, Mixed-potential-type zirconia-based NOx sensor using Rh-loaded NiO sensing electrode operating at high temperatures, Solid State Ion. 177 (2006) 2305-2311.

DOI: 10.1016/j.ssi.2005.12.023

[10] P. Elumalai, J. Wang, S. Zhuiykov, D. Terada, M. Hasei, N. Miura, Sensing characteristics of YSZ-based mixed-potential-type planar NOx sensors using NiO sensing electrodes sintered at different temperatures, J. Electrochem. Soc. 152 (2005).

DOI: 10.1149/1.1923707

[11] V.V. Plashnitsa, T. Ueda, N. Miura, Improvement of NO2 a sensing performances by an additional second component to the nano-structured NiO sensing electrode of a YSZ-based mixed-potential-type sensor, Int. J. Appl. Ceram. Technol. 3 (2006).

DOI: 10.1111/j.1744-7402.2006.02066.x

[12] N.F. Szabo, P.K. Dutta, Correlation of sensing behavior of mixed potential sensors with chemical and electrochemical properties of electrodes, Solid State Ion. 171 (2004) 183-190.

DOI: 10.1016/j.ssi.2004.04.019

[13] D.L. West, F.C. Montgomery, T.R. Armstrong, Use of La0. 85Sr0. 15CrO3 in high-temperature NOx sensing elements, Sens. Actuators B 106 (2005) 758-765.

[14] E.L. Brosha, R. Mukundan, R. Lujan, F.H. Garzon, Mixed potential NOx sensors using thin film electrodes and electrolytes for stationary reciprocating engine type applications, Sens. Actuators B 119 (2006) 398-408.

DOI: 10.1016/j.snb.2005.12.044

[15] E. Di Bartolomeo, M.L. Grilli, E. Traversa, Sensing mechanism of potentiometric gas sensors based on stabilized zirconia with oxide electrodes is it always mixed potential? J. Electrochem. Soc. 151 (2004) H133-H139.

DOI: 10.1149/1.1695387

[16] Q. Zhang, T. Wei, Y.H. Huang, Electrochemical performance of double-perovskite Ba2MMoO6 (M= Fe, Co, Mn, Ni) anode materials for solid oxide fuel cells, J. Power Sources 198 (2012) 59-65.

DOI: 10.1016/j.jpowsour.2011.09.092

[17] X. Yin, L. Hong, Partial oxidation of methane to syngas over the catalyst derived from double perovskite (La0. 5Sr0. 5)2FeNiO6−δ, Appl. Catal. A-Gen. 371 (2009) 153-160.

DOI: 10.1016/j.apcata.2009.09.044
