The Vibration Pickup of Micro-Pump Diaphragm Based on MEMS Technology Design

Abstract:

This paper designs a micro-pump silicon diaphragm vibration pickup sensor. In this newsensor which is based on piezoresistive effect, four MOSFETs with nc-Si/c-Si heterojunction drainand source are manufactured on the surface of silicon wafer by using the technique of CMOS andPECVD, at edge of <100> orientation of the N-type silicon diaphragm rectangle, and using MEMStechnology, the back of the four MOSFETs device silicon substrate processed into silicon cup, whichconstitutes the vibration pickup sensor. The micro-pump silicon diaphragm vibration pickup sensornot only has all the advantages of conventional force sensitive resistance vibration pickup sensor, butalso has the advantages of small temperature drift, high detection precision, and it can satisfy themicro-pump silicon diaphragm vibration requirements.

• Periodical: Key Engineering Materials (Volumes 609-610)
• Pages: 837-841
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.609-610.837
• Online since: April 2014
• Authors: Gang Li, Lei Li, Xiao Feng Zhao, Dian Zhong Wen*, Yang Yu
• Keywords: MEMS, Micro-Pump, Suspended Inductor, Vibration Pickup

References

[1] Wen Dianzhong, Sensitivity analysis of junction field effect-pressure halltron[J]. Review of Scientific Instrument. Vol. 66(1995) , pp.251-255.

DOI: 10.1063/1.1145267

[2] Lai P T, Spreading-resistance temperature sensor on silicon-on-insulator[J]. IEEE Electron Device letters. Vol. 20 (1999) , pp.589-591.

DOI: 10.1109/55.798053

[3] Aljancic U, Temperature effects modeling in silicon piezoresistive pressure sensor[C]. Electrotechnical Conference. 2002 MELECON , pp.36-40.

[4] Paschens J C, Dependence of thermal resistance on ambient and actual temperature[J]. Bipolar/BiCMOS Circuits and Technology. (2004) , pp.96-99.

[5] M. Fernandez-Bolanos, N. Abele, V. Pott, et al, Polyimide sacrificial layer for SOI SG-MOSFET pressure sensor[J]. Microelectronic Engineering. Vol. 83 (2006) , pp.1185-1188.

DOI: 10.1016/j.mee.2005.12.021

[6] Vitor Garcia, Fabiano Fruett, A mechanical-stress sensitive differential amplifier[J]. Sensors and Actuators A. Vol. 132 (2006) , p . 8-13.

DOI: 10.1016/j.sna.2006.06.060

[7] Maciej Oszwadowski, Tomasz Berus, High temperature hall sensors[J]. Sensors and Actuators A. Vol. 136 (2007) , p . 234-237.

DOI: 10.1016/j.sna.2006.11.023

[8] Wensheng Wei, Gangyi Xu, Tianmin wang, et al, Carrier conduction in heterojunction of hydrogenated nanocrystalline silicon with crystal silicon[J]. Thin Solid Films. Vol. 515 (2007) , pp.3997-4003.

DOI: 10.1016/j.tsf.2006.09.052

[9] Zhao Xiaofeng, Wen Dianzhong, Li Gang, Fabrication and characteristics of the nc-Si/c-Si heterojunction MOSFETs pressure sensor[J]. Sensors. Vol. 12 (2012) , pp.6369-6379.

DOI: 10.3390/s120506369
