Precision Control of Laser Beam Based on Liquid Crystal Spacial Light Modulator in Ultro-Precision Manufacturing

Abstract:

Laser beam precision control in ultro-precision manufacturing or other applications is to manipulate the beam pointing, intensity distribution, shape, far field patterns and so on. The method of beam control we used is different from traditional way that with mechanical inertia parts. The Liquid Crystal Spacial Light Modulator (LCSLM) is an electronic controlled, programmable diffractive device, which is able to modulate the phase of incident beam, therefore generate the objective patterns in far field. To establish the relationship between phase distribution of LCSLM and the far field objective function that represents the requirement of application, FFT and improved G-S algorithm are employed. Multi-beam focal point 3D control, beam shaping from Gaussian distribution to square and annular distribution with flat-top are discussed. They were studied in both theoretical and experimental ways. The results are evaluated by using error of root mean square and diffraction efficiency, which are less than 1% and higher than 90%, respectively.

• Periodical: Key Engineering Materials (Volume 613)
• Pages: 401-407
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.613.401
• Online since: May 2014
• Authors: Jian Zhang*, Li Ying Wu, Dong Wang
• Keywords: Diffractive Optics, G-S Algorithm, Laser Beam Control, Laser Precision Machining, Spacial Light Modulation

References

[1] Bertsch A, Y S Z J. Microstereolithography Using a Liquid Crystal Display as Dynamic Mask Generator[J]. Micro. Tech., 1997, 3(2): 42-47.

[2] A. Ruiz. de la Cruz A R, Ferrer A, Gawelda W, et al. Independent control of beam astigmatism and ellipticity using a SLM for fs-laser waveguide writing [J]. Optics Express, 2009, 17(23): 20853-20859.

DOI: 10.1364/oe.17.020853

[3] Beck R J, Parry J P, MacPherson W N, et al. Application of cooled spatial light modulator for high power nanosecond laser micromachining[J]. Optics Express, 2010, 18(16): 17059-17065.

DOI: 10.1364/oe.18.017059

[4] Engstrom D, Frank A, Backsten J, et al. Grid-free 3D multiple spot generation with an efficient single-plane FFT-based algorithm [J]. Optics Express, 2009, 17(12): 9989-10000.

DOI: 10.1364/oe.17.009989

[5] Whyte. G, Courtial J, Experimental demonstration of holographic three-dimensional light shaping using a Gerchberg-Saxton algorithm [J]. New Journal of physics, 2005, 7(117).

DOI: 10.1088/1367-2630/7/1/117

[6] 刘伯晗. 基于液晶空间光调制器的相干光波前实时变换的研究[D]. 哈尔滨工业大学仪器科学及技术2007：75-78.

DOI: 10.7498/aps.57.6360
