Optical Part Measuring inside a Milling Machine

Abstract:

The dimensions of a workpiece have been measured during the milling process using a 3D laser inspection system. Re-clamping of the work piece has been avoided but a short interruption of the milling process took place. All three dimensions of the part have been measured, height and width using a profile scanning devise based on the laser triangulation method and the length using also the displacement features of the machine tool. Gauge blocks with the reference dimension of 4, 8, 10, 14, 18 and 23 mm have been used for the verification of the measurements. The measured values for the height deviate from the real value between 0 to 19 μm. The deviations of the length lie between 0 and 33 μm. The deviations of the width are higher and they lie between 0 and 150 μm, because of the scanning steps of the devise. The measurement of the width could be improved using a second scanner perpendicular to the first one in order to achieve an overall part inspection with deviations lower than 33 μm.

You might also be interested in these eBooks

Measurement Technology and Intelligent Instruments XI

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 613)

Pages:

440-445

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.613.440

Citation:

Cite this paper

Online since:

May 2014

Authors:

Nicolas Meier*, Anthimos Georgiadis

Keywords:

In-Process Measurement, Micro Metrology, Optical Laser Inspection System, Profile Measurement, Zero-Defect Manufacturing

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] M. Glück, Die Produktion 2020, Computer & Automation (2012), Nr. 6, S. 47–50.

Google Scholar

[2] R. Schmitt, M. Harding, J. Lose, C. Mersmann, P. Jatzkowski, Anforderungen der Produktion, Verein Deutscher Ingenieure e.V. (Hrsg. ), Fertigungsmesstechnik 2020 : Technologie-Roadmap für die Messtechnik in der industriellen Produktion, S. 19. Düsseldorf : VDI/VDE, (2011).

DOI: 10.1007/978-3-662-24703-7_1

Google Scholar

[3] W. Osten, E. Garbusi, D. Fleischle, W. Lyda, C. Pruss, R. Reichle, C. Falldorf, Optical metrology from the laboratory to the real world, Proc. of SPIE 7387 (2010).

DOI: 10.1117/12.873356

Google Scholar

[4] W. Lyda, D. Fleischle, M. Gronie, F. Mauch, K. Körner, W. Osten, Herausforderungen und Lösungsansätze für die fertigungsnahe Qualitätskontrolle mittels optischer 3D-Messtechnik, 16. GMA/ITG-Fachtagung Sensoren und Messsysteme (2012).

DOI: 10.5162/sensoren2012/4.3.1

Google Scholar

[5] Keyence Corporation of America, High-speed Inline Profile Measurement Device: LJ-V7000 Series, Elmwood Park, (2012).

Google Scholar
