Design of Press Tools to Investigate the Hot Stamping Behaviour of Alternative Coatings for Press-Hardened Steel Parts

Abstract:

Due to oxidation and decarburization during heat treatment prior to hot stamping, various coating products have been developed in the last decades. Press-Hardened Steel (PHS) components for passenger cars are generally coated by aluminized or galvanized (GI) coatings. The aluminized coating presents a good formability at high temperature and permits forming and quenching components in the same press tools with a so called direct hot stamping method. Due to a strong cracking in the base material during direct hot stamping induced by liquid-metal embrittlement (LME), galvanized coated products must be pre-formed at low temperature and undergo heat treatment in separate press units. Moreover, the oxide scale formed on GI parts must be removed by abrasive blasting, whereas aluminized parts can be directly painted after hot forming. However, higher performance in corrosion resistance has been observed for galvanized parts, in particular in cosmetic and cut-edge corrosion. This increase is linked to the sacrificial effect or cathodic protection provided by the layer containing zinc. Daimler AG is investigating the possibility of improving performance of PHS body parts in terms of suitability for direct hot stamping and corrosion protection by developing new coating materials. In the following article, the main particularities and challenges involved in both current coating products will be introduced. The development of specific press tools for this study, as well as the corresponding simulation of hot forming will be presented. Finally, the hot forming behaviour and anticorrosive properties of both current products will be presented.

• Periodical: Key Engineering Materials (Volume 639)
• Pages: 227-234
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.639.227
• Online since: March 2015
• Authors: Damien Close*, Peter Feuser, Régis Lallement
• Keywords: Coating, Hot Stamping, Ultra-High Strength Steel

References

[1] Kolleck, R.; Veit, R.; Merklein, M.; Lechler, J.; Geiger, M.: Investigation on induction heating for hot stamping of boron alloyed steels. Annals of the CIRP 58/1/2009, pp.275-278.

DOI: 10.1016/j.cirp.2009.03.090

[2] Fan, D.W. F; Cooman, B.C.D.: State-of-the-Knowledge on Coating Systems for Hot Stamped Parts. Steel Research Int. 83 (2012) No. 5, pp.412-433.

DOI: 10.1002/srin.201100292

[3] Merklein, M.; Lechler, J.; Geiger, M.: Characterization of the Flow Properties of the Quenchable Ultra High Strength Steel 22MnB5. Annals of the CIRP 55/1/2006, pp.229-236.

DOI: 10.1016/s0007-8506(07)60404-1

[4] Hensen, G.; Melfo, W.; Chen, S.; Bleeker, R.; Verloop, W.: Developing Zinc Coated Boron Steel: Balancing Microcrack Performance and Corrosion Protection. Proceedings of 4th International Conference on Hot Sheet Metal Forming of High Performance Steel, Lulea, Sweden, 2013, pp.463-470.

[5] Singh, J.P.; Hall, J.N.; Coryelle, J. J: Challenges with Zinc-Coated Press Hardened Steel; Proceedings of 4th International Conference on Hot Sheet Metal Forming of High Performance Steel, Lulea, Sweden, 2013, pp.433-444.

[6] Dosdat, L.; Petitjean, J.; Vietoris, T.; Clauzeau, O.: Corrosion Resistance of Different Metallic Coatings on Press-Hardened Steels for Automotive. Steel Research Int. 82 (2011) No. 6, pp.726-733.

DOI: 10.1002/srin.201000291

[7] Zhong-Xiang, G.; Kai, Wang.; Yi-Sheng, Z.; Bin, Z.: Cracking and interfacial debonding of the Al-Si coating in hot stamping of pre-coated boron steel. Applied Surface Science 316, 2014, pp.595-603.

DOI: 10.1016/j.apsusc.2014.08.043

[8] Luckeneder, G.; Autengruber, R.; Stellnberger, K. -H.; Faderl, J.; Kurz, T.: Einflussfaktoren auf die Korrosionsschutzleistung von pressgehärteten Stahlwerkstoffen. ASMET: 3-Länder-Korrosionstagung, Linz, Austria, (2014).

[9] Close, D.; Lallement, R.; Feuser, P.; Bold, J.: Challenges in Corrosion Protection for Press-Hardened Steels; Tagungsband zum 9. Erlanger Workshop Warmblechumformung, Erlangen, Germany, 2014, pp.31-52.

[10] Allély, C.; Dosdat, L.; Clauzeau, O.; Ogle, K.; Volovitch, P.; Anticorrosion mechanisms of aluminized steel for hot stamping; Surface & Coatings Technology 238, 2014, pp.188-196.

DOI: 10.1016/j.surfcoat.2013.10.072
