Preparation of Mn-Zn Ferrite Flake Absorbent by Self-Reactive Spray Forming Technology

Abstract:

Fe+MnO +Fe2O3+ZnO reaction system was used to prepare Mn-Zn ferrite flake absorbent by self-reactive spray forming technology. Extrinsic enthalpy (H) and adiabatic temperature (Tad) of system were calculated. The formation mechanism and electromagnetic properties of Mn-Zn ferrite flake absorbent were analyzed. The results show that Tad exceeded 1998K, self-propagation reaction can be ignited and products can be melted. The droplets impacted onto copperplate to achieve flake shape. SEM and XRD were used to characterize the morphology and phase of samples. The results show that most of flake absorbent are at 100μm wide and 10μm thick, and they are constituted by pure Mn0.5Zn0.5Fe2O4 phase with spinel crystal structure. Absorption test show that the absorbent has two absorption peaks, the minimum value of reflectivity is at -27dB and the bandwidth lower than -10dB reaches to 3.5GHz. The Mn-Zn ferrite flake absorbent provides with preferable properties, which is potential in the further investigations.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 246-251
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.246
• Online since: May 2015
• Authors: Hai Tao Gao*, Jian Jiang Wang, Hong Fei Lou, Xu Dong Cai, Yong Shen Hou
• Keywords: Flake Absorbent, Mn-Zn Ferrite, Self-Reactive Spray Forming Technology

References

[1] Y B Feng, T Qiu, C Y Shen. Absorbing properties and structural design of microwave absorbers based on carbonyl iron and barium ferrite.J. Magn Magn Mater, 318 (2007) 8-10.

DOI: 10.1016/j.jmmm.2007.04.012

[2] S F Zheng, G X Xiong, H Q Huang, et al. Study on relation of Morphplogy, properties and preparation of ferrites. Mater Rev, 23(2009): 26-29.

[3] D Y Zhang, W Q Zhang, J Cai, Fabrication and electromagnetic properties of flake ferrite particles based on diatomite. J. Magn Magn Mater , 2011 (323): 2305-2309.

DOI: 10.1016/j.jmmm.2011.04.012

[4] Y F Cui, X Wang, Y F Jiang, et al. Study on Sintering Process of Mn-Zn Ferrite Nanopowders and Its Sintered Properties.J. Synth Cryst, 35(2006) 790-794.

[5] C F Zhang, H Y Yu, X C Zhong, et al. Study on Preparation of Mn-Zn Ferrite Materials by High-energy Ball Milling Method. Mater Rev, 23(2009) 8-10.

[6] S Y Sun, Y L Fang, Y K Fang, et al. Soft Magnetic Mn-Zn Ferrite Nanoparticles Prepared by Sol-Gel Auto-combustion. Magn Mater Dev, 35(2004) 21-26.

[7] G S Luo, G W Jiang, J D Li, et al. Effect of Heat Treatment on Structure and Magnetic Properties of Mn-Zn Ferrite. J. Nanchang Univ, 32(2010) 78-81.

[8] E J Lavernia, J Grantn. Spray deposition of materials: a review . J. Mater Sci Eng, 98(1988) 381-388.

[9] W Chen, Z Y Wang. The prospective of development trend about self-propagating thermal pressing technique. Mech Eng. 3(2005) 14-16.

[10] X D Cai. Study on the controllable preparation and microwave electromagnetism property of hollow ceramic micro-spheres. Shijiazhuang, (2012).

[11] J X Jiang, Y Li, X D Hao, et al. The combustion synthesis of Mn-Zn ferrite powders. J. Harbin Inst. Univ, 1(2004) 32-36.

[12] D G Xian, B S Lu, H K W. The principle and technology of manufacturing soft magnetic ferrite, Shanxi Sci. and Tech Publishing Inc, (2010).

[13] C S Liu, Y H Liu, S Yin. Inflience of extrinsic enthalpy on flame spray synthesis of TiC-Fe coating. J. Met, 36(2000) 1209-1212.

[14] D L Ye, J H Hu. Practical Handbook of the thermodynamic data for inorganic substances, Met Ind Publishing Inc, (2002).

[15] A G Merzhanov. Solid Flames: Discoveries, Concepts and Horizons of Cognition. J. Combust. Sci. and Tech, 98(1994)307-336.

DOI: 10.1080/00102209408935417

[16] K H Liu, Investigation on preparation and electromagnetic properties of microwave absorbers filled with flakes, Beijing, (2010).

[17] H F Lou, J J Wang, B C Xu, et al. Preparation by self-reactive quenching technology and microwave absorption property of hollow multiphase ceramic microspheres.J. Synth Cryst, 5(2012) 174-180.
