Design and Experimental Study of a Composite Materials Micro-Deformation Measurement Device

Abstract:

In the space environments, the size and weight of composite materials will produce small changes. In order to measure the small changes accurately, a micro-deformation measurement device has been designed. The carbon fiber tube was made from cyanate ester resin or epoxy resin was tested in vacuum and hygrothermal environments. The deformation in the vacuum test is -1.7 to 3.8 microns, in the hygrothermal test, the deformation is -1.3 to -6.4 microns. The same as theoretical analysis, the environmental stability of cyanate ester resin better than epoxy resin.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 869-874
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.869
• Online since: May 2015
• Authors: Ye Yuan*, He Bao, Hong Xu, Zhi Lai Li
• Keywords: Composite Material, Measurement Device, Micro-Deformation, Space Environments

References

[1] G.W. Meetham, M.H. Van de Voorde, Materials for High Temperature Engineering Applications, Springer, New York, (2000).

[2] R. Schutze. Lightweight Carbon Fiber Rods and Truss Structures. Materials and Design. 1997, 18: 231~238.

[3] JIANG X X, LAURIN D, LEVESQUE D, et al. Design and fabrication of a lightweight laser scanning mirror from metal-matrix composites. SPIE, 2001, 4444: 1-8.

DOI: 10.1117/12.447290

[4] AN Yuan, JIA Xue-zhi, ZHANG Lei. Optimizing design of CFRP based main backbone with high stiffness ratio for space camera. Optics and Precision Engineering, 2013, 21 (2) 416-422.

DOI: 10.3788/ope.20132102.0416

[5] Oshkovr SA, Eshkoor RA, Taher ST, Ariffin AK, Azhari CH. Crash worthiness characteristics investigation of silk/epoxy composite square tubes. Compos Struct 2012; 94: 2337–42.

DOI: 10.1016/j.compstruct.2012.03.031

[6] Wolff G E. Introduction to the Dimensional Stability of Composite Materials. Lancaster: DE Stech Publications, Inc. 2004: 1-419.

[7] Krenkel, W., and F. Berndt. C/C–SiC composites for space applications and advanced friction systems. Materials Science and Engineering: A 412. 1 (2005): 177-181.

DOI: 10.1016/j.msea.2005.08.204

[8] Dao B, Hodgkin J, Krstina J, Mardel J, Tian W. Accelerated ageing versus realistic ageing in aerospace composite materials–IV. Hot/wet ageing effects in a low temperature cure epoxy composite. J Appl Polymer Sci 2007; 106(6): 4264–76.

DOI: 10.1002/app.27104

[9] Fox B, Lowe A, Hodgkin J. Investigation of failure mechanisms in aged aerospace composites. Eng Fail Anal 2004; 11(2): 235–41.

DOI: 10.1016/j.engfailanal.2003.05.010

[10] Bondzic S, Hodgkin J, Krstina J, Mardel J. Chemistry of thermal ageing in aerospace epoxy composites. J Appl Polym Sci 2006; 100(3): 2210–9.

DOI: 10.1002/app.23692

[11] Yang Nai-bin. Present Status Analysis of Application of Composite Air frame Structure Abroad. Aeronautical Manufacturing Technology. 2002, (9): 21~23.

[12] Zhao Jia-xing. Application of Carbon Composite Materials for Civil Aviation. Hi-Tech Fiber and Application. 2003, 28(3): 1~5.

[13] Jeff W, Yap H, Murray L S. The Analysis of Skin-to-stiffener bonding in composite aerospace structures. Composite Structures. 2002, 57(1): 425~435.

DOI: 10.1016/s0263-8223(02)00110-1

[14] Hoskins and Baker. Composite Materials for Aircraft Structures. New York, American Institute of Aeronautics and Astronautics, Inc, 1986, 93~113.

[15] GUO, J., SHAO, M. D., WANG, G. L., et al. Design of optical-mechanical structure made of CFC in space remote sensing camera, Optics and Precision Engineering, 2012, 20 (3) 571-578.

DOI: 10.3788/ope.20122003.0571

[16] Lin Y, Chen X. Investigation of moisture diffusion in epoxy system: experiments and molecular dynamics simulations. Chem Phys Lett 2005; 412: 322–6.

DOI: 10.1016/j.cplett.2005.07.022

[17] WANG Zhen-ming, Mechanics of composite materials and composite material structural mechanics, Machinery Industry Press, Beijing, (1991).
