Basic Investigations on Joining of Metal and Fibre Components Based on the Semi-Solid Forming Process

Abstract:

The trend towards lightweight construction in automotive engineering causes additional effort and higher expense in vehicle manufacturing, because new materials or, respectively, new material combinations require adapted production and processing methods. Various combinations of metallic and fibre-based structures (GRP-/ CFRP components) presuppose convenient joining methods. In this context, an innovative joining method for combining sheet metals with carbon textiles is going to be developed at the Institute for Metal Forming Technology (IFU, University of Stuttgart / Germany). The goal of this research work is motivated by the prevention of any damage of the used textile fibre structures during the joining process (compared to mechanical joining methods like screwing or riveting). Based on the semi-solid forming technology, the new joining process is going to be developed to create a material integrated interlock between fibres and metallic components.This paper deals with the first fundamental investigations, conducted at IFU, which have already shown the technical feasibility of this new type of joining technique. The research work to be carried out comprises the usage of different sheet alloys: the combinations steel-aluminium, aluminium-aluminium and steel-steel are to be joined with layers of carbon fibre fabrics. By this innovative joining method, a firmly bonded and non-aging connection between textile and metallic materials is to be produced, without the need of any adhesive materials or associated preparative cleaning methods.

• Periodical: Key Engineering Materials (Volumes 651-653)
• Pages: 1445-1450
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.651-653.1445
• Online since: July 2015
• Authors: Lukas Marx*, Mathias Liewald, Kim Rouven Riedmüller
• Keywords: Bonding Technique, Carbon Fibres, Composite Material, MMC, Semi-Solid Forming

References

[1] P. Woizeschke, V. Wottschel, Recent Developments for Laser Beam Joining of CFRP-aluminum Structures, Procedia Materials Science, Vol. 2 (2013) 250–258.

DOI: 10.1016/j.mspro.2013.02.031

[2] W. Hufenbach, M. Gude, A. Czulak, J. Sleziona, A. Dolata-Grosz, M. Dyzia, Development of textile-reinforced carbon fibre aluminium composites manufactured with gas pressure infiltration methods, Journal of Achievements in Materials and Manufacturing Engineering, Vol. 35/2 (2009).

[3] S. Kreling, F. Fischer, Klebvorbehandlung per Lasertechnik, report, Hrsg.: Institut für Füge- und Schweißtechnik, Nr. 1, (2012).

[4] R. Wilken, Aspekte zum qualitätsgesicherten Kleben von CFK-Komponenten, Lightweight Design 3 (2011) 33-37.

DOI: 10.1365/s35725-011-0030-y

[5] S. Kreling, D. Blass, F. Fischer, K. Dilger, Sauber und prozesssicher, adhäsion KLEBEN & DICHTEN 3 (2013) 24-29.

DOI: 10.1365/s35145-013-0216-9

[6] M. Pröbster, Elastisch Kleben, Springer Fachmedien Wiesbaden, (2013).

[7] P. Unseld, Ein Beitrag zur Herstellung metallischer Verbundwerkstoffe durch teilflüssige/ thixotrope Formgebung, Dissertation at the University of Stuttgart (2009).

DOI: 10.37544/1436-4980-2008-10-871

[8] K.R. Riedmüller, M. Liewald, L. Kertesz, Manufacturing of Composite and Hybrid Metals by Semi Solid Forming, 12th International Conference Semi-Solid Processing of Alloys and Composites (S2P2012), CSIR, Cape Town, South Africa (2012).

DOI: 10.4028/www.scientific.net/ssp.192-193.89

[9] M. Liewald, K.R. Riedmüller, Material Property Modification of Continuous Fibre-reinforced Aluminium Matrices Produced by Semi-solid Forming Strategies, KMUTNB: IJAST, Vol. 7, 3 (2014) 21-28.

DOI: 10.14416/j.ijast.2014.07.003

[10] H.V. Atkinson, Introduction to Modelling Semi-Solid Processing, in Modelling of Semi-Solid Processing, H.V. Atkinson (Ed), Shaker (2008) 1-19.

[11] M. Modigell, A. Pola, M. Suéry, C. Zang, Investigation of correlations between shear history and microstructure of semi-solid alloys, 12th International Conference Semi-Solid Processing of Alloys and Composites (S2P2012), CSIR, Cape Town, South Africa (2012).

DOI: 10.4028/www.scientific.net/ssp.192-193.251

[12] K. Siegert, G. Messmer, P. Unseld, P. Delinasakis, Producing near net shape parts with high mechanical properties by thixoforging, International Conference Advanced Metallic Materials, 5-7 November, Smolenice, Slovakia, (2003).

[13] Dynamic Systems Inc., Gleeble Users Training 2009, Gleeble Systems and Applications.

[14] N. Jank, H. Staufer, J. Bruckner, Schweißverbindungen von Stahl mit Aluminium – eine Perspektive für die Zukunft, BHM Berg- und Hüttenmännische Monatshefte 5 (2008) 189-192.

DOI: 10.1007/s00501-008-0373-6
