Optimal Structural Design of Micro-Motion Stage with Stiffness Constraints Using Topology and Sizing Optimization Method

Abstract:

Flexure hinge is widely used in the compliant mechanisms for precision engineering. Generally, compliant mechanisms with flexure hinges are designed using the analytical stiffness formulas, which increases the design complexity. As the development of finite element analysis (FEA) and optimization methods, it is likely to design the flexure hinges directly using the FEA based numerical optimization methods. This paper developed a leaf spring type flexure hinge based micro-motion stage with specific stiffness constraints. Both topology and sizing optimization methods are used in the design of motion stage. The proposed methods is apply to optimal design formed the leaf spring type flexure hinge for a micro motion stage which serves as a guidance mechanism. Further numerical result shows the good stiffness stability of the refined stage.

• Periodical: Key Engineering Materials (Volume 679)
• Pages: 55-58
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.679.55
• Online since: February 2016
• Authors: You Dun Bai*, Zhi Jun Yang, Xin Chen, Meng Wang
• Keywords: Micro Motion Stage, Sizing Optimization, Stiffness Constraint, Topology Optimization

References

[1] Howell LL. Compliant mechanisms: John Wiley & Sons, (2001).

[2] Zubir M, Shirinzadeh B, Tian YL. Development of a novel flexure-based microgripper for high precision micro-object manipulation. Sensor Actuat A-Phys 2009; 150: 257.

DOI: 10.1016/j.sna.2009.01.016

[3] Tian Y, Shirinzadeh B, Zhang D. A flexure-based mechanism and control methodology for ultra-precision turning operation. Precis Eng 2009; 33: 160.

DOI: 10.1016/j.precisioneng.2008.05.001

[4] Tian Y, Liu X, Zhang D, Chetwynd DG. Dynamic modelling of the fidelity of random surface measurement by the stylus method. Wear 2009; 266: 555.

DOI: 10.1016/j.wear.2008.04.061

[5] Tian Y, Shirinzadeh B, Zhang D, Zhong Y. Three flexure hinges for compliant mechanism designs based on dimensionless graph analysis. Precision Engineering 2010; 34: 92.

DOI: 10.1016/j.precisioneng.2009.03.004

[6] M PJ, L W. How to design flexure hinges. Machine Design 1965; 37: 151.

[7] Yong YK, Lu T, Handley DC. Review of circular flexure hinge design equations and derivation of empirical formulations. Precis Eng 2008; 32: 63.

DOI: 10.1016/j.precisioneng.2007.05.002

[8] BenLiang Z, XianMin Z, Fatikow S. Design of single-axis flexure hinges using continuum topology optimization method. SCIENCE CHINA-TECHNOLOGICAL SCIENCES 2014; 57: 560.

DOI: 10.1007/s11431-013-5446-4

[9] Bharanidaran R, Ramesh T. Numerical simulation and experimental investigation of a topologically optimized compliant microgripper. Sensor Actuat A-Phys 2014; 205: 156.

[10] Wiersma DH, Boer SE, Aarts R, Brouwer DM. Design and Performance Optimization of Large Stroke Spatial Flexures. JOURNAL OF COMPUTATIONAL AND NONLINEAR DYNAMICS 2014; 9.

DOI: 10.1115/1.4025669

[11] Du Z, Shi R, Dong W. A Piezo-Actuated High-Precision Flexible Parallel Pointing Mechanism: Conceptual Design, Development, and Experiments. IEEE TRANSACTIONS ON ROBOTICS 2014; 30: 131.

DOI: 10.1109/tro.2013.2288800
