Effects of Axial Spindle Vibration on Surface Generation in Ultra-Precision Diamond Turning

Abstract:

In ultra-precision diamond turning (UPDT), axial spindle vibration (ASP) plays a crucial role influencing nanometric surface quality. In this study, a simplified model for ASP is proposed to study its effects on surface generation in UPDT as the spindle is idealized as a mass-spring-damper system. Significantly, the model successfully explains that ASP induces radial patterns at a machined surface. More importantly, this proposed model can be employed to easily predict and understand the effects of ASP on surface generation in UPDT.

• Periodical: Key Engineering Materials (Volume 679)
• Pages: 67-71
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.679.67
• Online since: February 2016
• Authors: Shao Jian Zhang*, Suet To
• Keywords: Model, Spindle Vibration, Surface Generation, Ultra-Precision Diamond Turning
