Development of a Process Map for Wire Drawing of Pearlitic Steel by Finite Element Analysis Coupled with Damage Evolution

Abstract:

This work is concerned with the development of a new process map for wire drawing of pearlitic steel considering damage evolution. In this study, a ductile damage is defined as a porosity or void volume fraction and the porosity evolution model proposed by Lee and Dawson is adopted. Dilatational plastic deformation due to growth of micro voids is also considered. Correspondingly, an Eulerian finite element analysis coupled with damage evolution model is utilized in order to reflect the effects of dilatational plasticity due to growth of micro voids. Also, the accumulated damage in wire drawing could be evaluated. Finite element simulation for wire drawing of pearlitic steel are performed for various process conditions such as a half die angle and an area reduction ratio. Especially, the effects of process parameters on the deformation characteristic as well as damage evolution in wire drawing are carefully examined. Finally, a new process map is presented in terms of a half die angle and an area reduction ratio, which can identify the successful process conditions for wire drawing of pearlitic steel. Thus, it would be expected that this process map will help an engineer for the design of wire drawing of pearlitic steel.

• Periodical: Key Engineering Materials (Volume 716)
• Pages: 652-658
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.716.652
• Online since: October 2016
• Authors: Yong Shin Lee*
• Keywords: Damage Evolution, Eulerian Finite Element Method, Pearlitic Steel, Process Map for Wire Drawing, Wire Drawing

References

[1] B. Avitzur, Analysis of Central Bursting Defects in Extrusion and Wire Drawing, Transactions of the ASME Journal of Engineering for Industry. 90 (1968) 79-91.

DOI: 10.1115/1.3604608

[2] P. Phelean, J. Brandon, M. Hillery, Central Burst Defect Analysis of the Wire-Drawing Process using an Accumulated Damage Parameter, Proc. Inst. Mech. Eng. 215 Part C (2001) 1313.

DOI: 10.1243/0954406011524694

[3] K. Komori, Effect of Ductile Fracture Criterio on Chevron Crack Formation and Evolution in Drawing, Int. J. Mech. Sci. 45 (2003) 141-150.

DOI: 10.1016/s0020-7403(03)00035-3

[4] C.M. Bae, W.J. Nam, C.S. Lee, Effect of Interlamellar Spacing on the Delamination of Pearlitic Steel Wires, Scripta Mater. 35 (1996) 641-646.

DOI: 10.1016/1359-6462(96)00183-2

[5] J. Languillaume, n G. Kapelski, B. Baudelet, Cementite Dissolution in Heavily Cold Drawn Pearlitic Stell Wires, Acta Mater. 45 (1997) 1201-1212.

DOI: 10.1016/s1359-6454(96)00216-9

[6] W.J. Nam, C.M. Bae, Parameters Affecting on Wire Drawability of Pearlitic Steel, Trans. Mat. Processing. 12 (2003) 610-614.

[7] W.J. Nam, C.M. Bae, Void Initiation and Microstructural Changes During Wire Drawing of Pearlitic Steels, Mat. Sci. Eng. 203 (1995) 278-285.

DOI: 10.1016/0921-5093(95)09826-7

[8] J.R. Rice and D.M. Tracey, On the ductile enlargement of voids in triaxial stress fields, Journal of Mechanics and Physics of Solids. 17 (1969) 201-217.

DOI: 10.1016/0022-5096(69)90033-7

[9] A.C.F. Cocks and M.F. Ashby, Creep fracture by coupled power-law creep and diffusion under multiaxial stress, Met. Sci. Vol. 16 (1982) 465-474.

DOI: 10.1179/msc.1982.16.10.465

[10] Krajcinovic, Continuum damage mechanics revisited: Basic Concepts and Definitions, ASME J Appl Mech. 52 (1985) 829-834.

DOI: 10.1115/1.3169154

[11] Y. -S. Lee, P.R. Dawson, Modeling ductile void growth in hardening viscoplastic materials, Mech Mater. 15 (1993) 21-24.

[12] S. Yoon, Y. -S. Lee, W.J. Nam, K.T. Park, D.J. Yoon, Comparative study of damage evolution model, Proceeding of KSTP 2008 Spring Meeting, (2008), pp.899-900.

[13] M.G. Cockroft and D.J. Latham, Ductility and the workability of metals, J. Inst. Met. 96 (1968) 33-39.

[14] P. Brozzo, B. deLuka, R. Rendina, A new method for the prediction of formability in metal sheets, Proceeding of 7th Biennial conference on Sheet Metal Forming and Formability, (1972).

[15] M. Oyane, Criteria of ductile fracture strain, Bull. Of JSME, Vol. 15 (1972), pp.1507-1513.

DOI: 10.1299/jsme1958.15.1507

[16] Y. -S. Lee, An Eulerian Finite Element Method for the Steady State Forming of Porous Materials, Metals and Materials, International, 12 N0. 2 (2006) 161-166.

DOI: 10.1007/bf03027473
