Finite Element Simulation of Shear Strain during High-Ratio Differential Speed Rolling of Aluminum Alloy 5083

Abstract:

High-ratio differential speed rolling (HRDSR) is a process of severe plastic deformation (SPD) that can be used to improve the structure and properties of aluminum alloys. The mechanism of SPD during HRDSR comes from its large equivalent strain, which is composed of compressive strain and additional shear strain. Plastic strain control of aluminum alloys are of importance for improvement of sheet microstructure and properties. This paper presents the results of the finite element simulation of shear strain during high-ratio differential speed rolling of aluminum alloy 5083. Four deformation routes UD, TD, RD and ND were simulated. By the route UD the sheet was not rotated between two deformation steps, while by the other three cases it was rotated with 180° degrees. By the route RD the rotation axis was the rolling direction, by the route TD the transverse direction and by the route ND the normal direction. The effect of rolls velocity ratio, friction coefficient and deformation route on the shear strain and the effective strain of Al 5083 was found. The results of investigation can be used to optimize the high-ratio differential speed rolling process to improve microstructure and mechanical properties of aluminum sheets.

• Periodical: Key Engineering Materials (Volume 716)
• Pages: 700-707
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.716.700
• Online since: October 2016
• Authors: Alexander Pesin*, D.O. Pustovoytov
• Keywords: Aluminium Alloy, Finite Element Method (FEM), High-Ratio Differential Speed Rolling, Shear Strain

References

[1] Y.H. Ji, J.J. Park, W.J. Kim, Finite element analysis of severe deformation in Mg-3Al-1Zn sheets through differential-speed rolling with a high speed ratio, Mat. Sci. Eng. A. 454-455 (2007) 570-574.

DOI: 10.1016/j.msea.2006.11.076

[2] Y.H. Ji, J.J. Park, Development of severe plastic deformation by various asymmetric rolling processes, Mat. Sci. Eng. A. 499 (2009) 14-17.

DOI: 10.1016/j.msea.2007.11.099

[3] J. Jiang, Y. Ding, F. Zuo, A. Shan, Mechanical properties and microstructures of ultrafine-grained pure aluminum by asymmetric rolling, Scripta Mater. 60 (2009) 905-908.

DOI: 10.1016/j.scriptamat.2009.02.016

[4] F. Zuo, J. Jiang, A. Shan, Shear deformation and grain refinement in pure Al by asymmetric rolling, Transactions of Nonferrous Metals Society of China, 18 (2008) 774-777.

DOI: 10.1016/s1003-6326(08)60133-8

[5] Q. Cui, K. Ohori, Grain refinement of high purity aluminum by asymmetric rolling, Mater. Sci. Tech. 16 (2000) 1095-1101.

DOI: 10.1179/026708300101507019

[6] M. Sverdlik, A. Pesin, D. Pustovoytov, A. Perekhozhikh, Numerical research of shear strain in an extreme case of asymmetric rolling, Advanced Materials Research. 742 (2013) 476-481.

DOI: 10.4028/www.scientific.net/amr.742.476

[7] W.J. Kim, B.G. Hwang, M.J. Lee, Y.B. Park, Effect of speed-ratio on microstructure, and mechanical properties of Mg-3Al-1Zn alloy, in differential speed rolling, J. Alloy. Compd. 509 (2011) 8510-8517.

DOI: 10.1016/j.jallcom.2011.05.063

[8] A. Pesin, D. Pustovoytov, Influence of Process Parameters on Distribution of Shear Strain through Sheet Thickness in Asymmetric Rolling, Key Engineering Materials. 622-623 (2014) 929-935.

DOI: 10.4028/www.scientific.net/kem.622-623.929

[9] A. Pesin, M. Chukin, A. Korchunov, D. Pustovoytov, Finite Element Modeling of Shear Strain in Rolling with Velocity Asymmetry in Multi-Roll Calibers, Key Engineering Materials. 622-623 (2014) 912-918.

DOI: 10.4028/www.scientific.net/kem.622-623.912

[10] A. Pesin, A. Korchunov, D. Pustovoytov, Numerical Study of Grain Evolution and Dislocation Density during Asymmetric Rolling of Aluminum Alloy 7075, Key Engineering Materials. 685 (2016) 162-166.

DOI: 10.4028/www.scientific.net/kem.685.162

[11] J.J. Park, Finite-element analysis of severe plastic deformation in differential-speed rolling, Comp. Mater. Sci. 100 (2015) 61-66.

DOI: 10.1016/j.commatsci.2014.09.010

[12] Loorentz, Y.G. Ko, Effect of differential speed rolling strain on microstructure and mechanical properties of nanostructured 5052 Al alloy, J. Alloy. Compd. 586 (2014) S205-S209.

DOI: 10.1016/j.jallcom.2012.10.128

[13] J.K. Lee, D.N. Lee, Texture Evolution and Grain Refinement in AA1050 Aluminum Alloy Sheets Asymmetrically Rolled with Varied Shear Directions, Key Engineering Materials. 340-341 (2007) 619-626.

DOI: 10.4028/www.scientific.net/kem.340-341.619

[14] J.K. Lee, D.N. Lee, Texture control and grain refinement of AA1050 Al alloy sheets by asymmetric rolling, Int. J. Mech. Sci. 50 (2008) 869-887.

DOI: 10.1016/j.ijmecsci.2007.09.008

[15] K. Bobor, Z. Hegedus, J. Gubicza, I. Barkai, P. Pekker, G. Krallics, Microstructure and mechanical properties of Al 7075 alloy processed by differential speed rolling, Periodica Polytechnica Mechanical Engineering. 56 (2012) 111-115.

DOI: 10.3311/pp.me.2012-2.06

[16] A. Pesin, D. Pustovoytov, T. Shveyova, M. Sverdlik, Finite Element Modeling of Roll Wear during Cold Asymmetric Sheet Rolling of Aluminum Alloy 5083, MATEC Web of Conferences. 26 (2015) 1-4.

DOI: 10.1051/matecconf/20152601010
