Influence of Material and Tribological Modelling on the Prediction of Big Size Automotive Components Springback

Abstract:

The finite element simulation has become an essential tool for the proper design of big size automotive components stamping tooling and their process optimization. Although big improvements have been made in the last years in terms of material and tribological modelling, the accuracy of the current models should be further improved to estimate the final post-forming springback of these components, in both AHSS and mild steels.In the present paper the forming of a B-Pillar reinforcement is numerically analyzed using a DX54D mild steel and a TRIP800 high strength steel. In the first part, the influence of the elastic behavior including variable young modulus, the yield criteria and the hardening law on the final springback is studied for both materials. Secondly, the friction coefficient is defined constant and pressure dependent and springback variation is analyzed in function of this variable.In order to stablish the material and friction variables and their typical deviation, results obtained from material characterization and strip drawing tests are used.

• Periodical: Key Engineering Materials (Volume 716)
• Pages: 713-718
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.716.713
• Online since: October 2016
• Authors: Imanol Gil*, Endika Mugarra, Julen Agirre, Joseba Mendiguren, Eneko Sáenz de Argandoña, Lander Galdos
• Keywords: Deep Drawing, Finite Element Method (FEM), Influencing Variables, Springback

References

[1] P. -A. Eggertsen, K. Mattiasson, Experiences from experimental and numerical springback studies of a semi-industrial forming tool, Int. J. Mater. Form. 5 (2012) 341–359.

DOI: 10.1007/s12289-011-1052-9

[2] J. Chen, Y. Xiao, W. Ding, X. Zhu, Describing the non-saturating cyclic hardening behavior with a newly developed kinematic hardening model and its application in springback prediction of DP sheet metals, J. Mater. Process. Tech. 215 (2015).

DOI: 10.1016/j.jmatprotec.2014.08.014

[3] F. Wang, Y. -P. You, Finite element analysis on influencing factors of springback in sheet metal V-bending, Shenyang GongyeDaxueXuebao/Journal Shenyang Univ. Technol. 34 (2012) 526–529+535.

[4] M. Koc, P. Chen, Simulation of springback variation in forming of advanced high strength steels, J. Mater. Process. Tech. 190 (2007) 189–198.

[5] F. Yoshida, T. Uemori, A model of large-strain cyclic plasticity describing the Bauschinger effect and workhardening stagnation, Int. J. Plasticity. 18 (2002) 661–686.

DOI: 10.1016/s0749-6419(01)00050-x

[6] R.M. Cleveland, a.K. Ghosh, Inelastic effects on springback in metals. Int. J. Plasticity. 18 (2002) 769–785.

DOI: 10.1016/s0749-6419(01)00054-7

[7] J. Mendiguren, Experimental and numerical analysis of the elastic behaviour of the TRIP 700 steel for springback predictions (2012), Thesis work.

[8] D. Banabic, Sheet Metal Forming Processes (2010).

[9] P. -A. Eggertsen, K. Mattiasson, On constitutive modeling for springback analysis. Int. J. Mech. Sci. 52 (2010) 804–818.

DOI: 10.1016/j.ijmecsci.2010.01.008

[10] B. Peeters, A theoretical investigation of the influence of dislocation sheets on evolution of yield surfaces in single-phase B.C.C. polycrystals, J. Mech. Phys. Solids. 50 (2002) 783–807.

DOI: 10.1016/s0022-5096(01)00094-1

[11] J. -Y. Lee,F. Barlat, M. -G. Lee, Constitutive and friction modeling for accurate springback analysis of advanced high strength steel sheets, Int. J. Plasticity. 71 (2015) 113–135.

DOI: 10.1016/j.ijplas.2015.04.005

[12] H. Kudo, A. Azushima, Interaction of surface microstructure and lubricant in metal forming tribology, In Proc. 2nd. Int. Conf. On Adv. Technol. of Plasticity (1987) 373–384.

[13] M. Merklein, F. Zoeller, V. Sturm, Experimental and numerical investigations on frictional behaviour under consideration of varying tribological conditions, Advanced Materials Research (2014) 966-967, 270–278.

DOI: 10.4028/www.scientific.net/amr.966-967.270

[14] S.S. Han, Contact Pressure dependent frictional characteristics of hot-dip galvanized high strength steel sheet and its effect on springback behavior, In 11th Asia-Pacific Conference on Engineering Plasticity and Its Applications, AEPA (2012).

DOI: 10.4028/www.scientific.net/kem.535-536.250

[15] K. Dohda, Z. Wang, Effects of average lubricant velocity and sliding velocity on friction behavior in mild steel sheet forming, J. tribol. 120(4) (1998) 724–728.

DOI: 10.1115/1.2833771

[16] J. Mendiguren, F. Cortes, L. Galdos, S. Berveiller, Strain path's influence on the elastic behaviour of the TRIP 700 steel, Mater. Sci. Eng. A. 560 (2013) 433-438.

DOI: 10.1016/j.msea.2012.09.087
