Large Deflection Response of Rectangular Metal Sandwich Plates with Functionally Graded Foam Core Subjected to Blast Loading

Abstract:

A theoretical research is carried out to study the large deflection response of a fully clamped rectangular metal sandwich plates with functionally graded foam core subjected to blast loading. Using a new yield criterion for sandwich cross-section with graded foam core, we obtained the analytical solutions for the dynamic response of rectangular sandwich plates. Finite element simulations with gradient layers foam core model are performed to study the dynamic response of the sandwich plates with graded foam core subjected to blast loading. The results of the analyses seem to predict well the deflections that are given numerically.

• Periodical: Key Engineering Materials (Volume 725)
• Pages: 149-155
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.725.149
• Online since: December 2016
• Authors: Chun Ping Xiang, Qing Hua Qin*, Fang Fang Wang, Ming Shi Wang, Xue Hui Yu, Tie Jun Wang
• Keywords: Blast Loading, Dynamic Response, Graded Foam Core, Large Deflection, Sandwich Plates

References

[1] N.A. Fleck, V.S. Deshpande, The resistance of clamped sandwich beams to shock loading, J. Appl. Mech. 71 (2004) 386-401.

DOI: 10.1115/1.1629109

[2] X. Qiu, V.S. Deshpande, N.A. Fleck, Dynamic response of a clamped circular sandwich plate subject to shock loading, J. Appl. Mech. 71 (2004) 637-645.

DOI: 10.1115/1.1778416

[3] Q. Qin, C. Yuan, J. Zhang, T.J. Wang, Large deflection response of rectangular metal sandwich plates subjected to blast loading, Eur. J. Mech. A/Solids. 47 (2014) 14-22.

DOI: 10.1016/j.euromechsol.2014.02.016

[4] N.A. Apetre, B.V. Sankar, D.R. Ambur, Low-velocity impact response of sandwich beams with functionally graded core, Int. J. Solids. Struct. 43 (2006) 2479-2496.

DOI: 10.1016/j.ijsolstr.2005.06.003

[5] X.R. Liu, X.G. Tian, T.J. Lu, B. Liang, Sandwich plates with functionally graded metallic foam cores subjected to air blast loading, Int. J. Mech. Sci. 84 (2014) 61-72.

DOI: 10.1016/j.ijmecsci.2014.03.021

[6] S. Li, X. Li, Z. Wang, G. Wu, G. Lu, L. Zhao, Finite element analysis of sandwich panels with stepwise graded aluminum honeycomb cores under blast loading, Compos. Part A Appl. Sci. Manuf. 80 (2016) 1-12.

DOI: 10.1016/j.compositesa.2015.09.025

[7] V.S. Deshpande, N.A. Fleck, High strain rate compressive behaviour of aluminium alloy foams, Int. J. Impact. Eng. 24 (2000) 277-298.

DOI: 10.1016/s0734-743x(99)00153-0

[8] M.F. Ashby, A.G. Evans, N.A. Fleck, L.J. Gibson, J.W. Hutchinson, H.N.G. Wadley. Metal Foams: A Design Guide. Butterworth-Heinemann, Oxford, (2000).

DOI: 10.1016/b978-075067219-1/50001-5

[9] S.P. Santosa, T. Wierzbicki, A.G. Hanssen, M. Langseth, Experimental and numerical studies of foam-filled sections, Int. J. Impact. Eng. 24 (2000) 509-534.

DOI: 10.1016/s0734-743x(99)00036-6

[10] N. Jones. Structural Impact (Second Edition). Cambridge University Press, Cambridge, (2012).

[11] Q.H. Qin, F.F. Wang, W.L. Ai, M.S. Wang, Z.J. Wang, T.J. Wang, Plastic analysis of metal sandwich beams with a functionally graded core at finite deflection under transverse loading, Prepared, (2016).

[12] V.S. Deshpande, N.A. Fleck, Isotropic constitutive models for metallic foams, J. Mech. Phys. Solids. 48 (2000) 1253-1283.

DOI: 10.1016/s0022-5096(99)00082-4
