Effect of Printing Temperature on Mechanical Properties and Surface Quality of Photosensitive Resin Rapid Prototyping Parts

Abstract:

Abstract. The rapid prototypes of different printing temperature by Objet30 Stratasys Pro printer were found a certain difference in performance in the process of using the process.In order to studied the effect of printing temperature on the rapid prototyping of photosensitive resin, tensile and bending tests were carried out on the rapid prototyping parts at 12°C, 18°C, 21°C, 23°C, 25°C, 30°C,respectively,and the rigidity and surface roughness of rapid prototyping parts were measured.Research shows：the tensile strength increases with the increase of printing temperature , tensile elastic modulus fluctuates with the printing temperature , they all increases rapidly after 25°C;The bending strength increases proportional with the increase of printing temperature, and the bending modulus increases first and then tends to decrease with the increase of printing temperature;The hardness value increases slowly with the increase of printing temperature, and increases obviously after 20°C,the hardness value in the middle of the prototype parts is bigger than the edge parts；The surface roughness with increasing printing temperature, although it is floating up and down, but have little effect.

• Periodical: Key Engineering Materials (Volume 727)
• Pages: 466-470
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.727.466
• Online since: January 2017
• Authors: Xian Yong Zhu, Fei Fei Cui, Cheng Jiang, Dong Ni Geng, Xue Lei Xu, Yun Chao Zhou
• Keywords: Mechanical Properties, Performance, Photosensitive Resin, Printing Temperature, Rapid Prototyping, Surface Quality

References

[1] Huang S H, Xiao Y J, Mo J H, et al. Prospect of rapid prototyping technology[J]. China Mechanical Engineering, 2000, 1: 195-200. (In Chinese).

[2] Liu H T, Huang S H, Mo J H, et al. Effect of photosensitive resin on surface quality of rapid prototyping parts [J]. polymer materials science and engineering, 2007, 5: 170-173. (In Chinese).

[3] Wang Kui, Jiang Hai, Jiang Kerong. Application and development of stereo light curing rapid prototyping technology [J]. new technology and technology, 2008, 2008 (2): 55-56. (In Chinese).

[4] Ferry P.W. Melchels, Jan Feijen, Dirk W. Grijpma. A review on stereolithography and its applications in biomedical engineering. [J]. Biomaterials, 2010, 31: 6121–6130.

DOI: 10.1016/j.biomaterials.2010.04.050

[5] Xie Biao. Modified [D]. of photosensitive resin for light curing 3D printing, Qingdao University of Science & Technology, 2015. (In Chinese).

[6] Liu Li, Liang Yande. Stereolithography photosensitive resin for [J]. materials review, 2005, 19 (F05): 229-231. (In Chinese).

[7] Fan Hualiang, Cao Xiangqun. The photosensitive resin curing mechanism [J]. Acta PHOTONICA Sinica, 1994 (2): 168-173. (In Chinese).

[8] Wu Xiaoxia, Yang Haiou. Effects of different temperature and different light curing light on the hardness of light cured composite resin[J]. Shanghai Journal of medicine, 2010, 19(1): 104-106. (In Chinese).

[9] Ma Guozhang, Wu Jianbing, Xu and she. Infrared spectroscopy study on the conversion of C=C double bonds in UV curing dark reaction [J]. spectroscopy and spectral analysis, 2010, 30 (7): 1780-1784. (In Chinese).

[10] Yao Zhibao. Different temperature and light source on the surface hardness of light cured composite resin [J]. Journal of Practical Stomatology, 2008, 24 (5)：647-649. (In Chinese).

[11] Yang Yuanli, Wang Yongzhen, Wang Ailing. Study on the curing mechanism of photosensitive resin in light curing rapid prototyping [J]. materials development and application, 2006, 21 (6): 8-10. (In Chinese).
