Effects of Chromium Content on Thermal Shock Cycle Resistance of (TiCr)N Hard Reactive Films

Abstract:

The (TiCr)N hard reactive films with 4 different Ti/Cr atomic ratios are prepared by using multi-arc ion plating. The Ti and Cr targets are used as cathodes in the co-deposition process. The high speed steel (HSS) specimens are adopted as substrate. The thermal shock cycle tests in air cooling (AC) way for the (TiCr)N films are carried out. The test temperatures are chosen as 600 °C and 700 °C, respectively. The changes of the surface compositions and morphology in the thermal shock cycle tests are investigated. The effects of Cr content in the (TiCr)N films, the temperature at which the thermal shock cycle tests are performed and the cycling times on the thermal shock resistance of the (TiCr)N films are discussed and analyzed in detail. The thermal shock behaviors of the (TiCr)N films show that the thermal shock cycling process of the (TiCr)N films consists of two stages, the steady-state oxidation stage with the increase of oxygen content at the early stage of thermal cycles, and, the instable oxidation stage with the oxidation aggravation and the occurrence of the surface cracks. The simple increase of Cr content in the (TiCr)N film does not improve the thermal shock resistance of the (TiCr)N films but easy to aggravate the surface oxidation process during the thermal shock cycles.

• Periodical: Key Engineering Materials (Volume 737)
• Pages: 150-155
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.737.150
• Online since: June 2017
• Authors: Bu Shi Dai, Jun Zhang*
• Keywords: (TiCr)N Hard Reactive Films, Composition, Multi Arc Ion Plating, Thermal Shock Cycle

References

[1] J. G. Han, H. S. Myung, H. M. Lee, L. R. Shaginyan, Microstructure and mechanical properties of Ti–Ag–N and Ti–Cr–N superhard nanostructured coatings, Surf. Coat. Technol. 174-175 (2003) 738-742.

DOI: 10.1016/s0257-8972(03)00565-6

[2] D. J. Li, F. Liu, M. X. Wang, J. J. Zhang, Q. X. Liu, Structural and mechanical properties of multilayered gradient CrN/ZrN coatings, Thin Solid Films 506-507 (2006) 202-206.

DOI: 10.1016/j.tsf.2005.08.031

[3] G. G. Fuentes, M. J. Díaz de Cerio, J. A. García, R. Martínez, R. Bueno, R. J. Rodríguez, M. Rico, F. Montalá, Y. Qin, Gradient CrCN cathodic arc PVD coatings, Thin Solid Films 517(20) (2009) 5894-5899.

DOI: 10.1016/j.tsf.2008.08.005

[4] Z. H. Cai, Y. L. Di, J. W. He et al. Investigation of Microstructure and Tribological Properties of Crx Ti1-xN Composite Films on Piston Ring, Adv. Mater. Res. 287-290 (2011) 2148-2151.

[5] S. Samapisut, U. Tipparach, G. Heness, G. McCredie, Effect of magnetrondischarge power and N2 flow rate for preparation of TiCrN thin film, Procedia Eng. 32 (2012) 1135-1138.

DOI: 10.1016/j.proeng.2012.02.067

[6] G. Kirchhoff, Th. Gobel, H. -A. Bahr, H. Balke, K. Wetzig, K. Bartsch, Damage analysis for thermally cycled (Ti, Al)N coatings—estimation of strength and interface fracture toughness, Surf. Coat. Technol. 179(1) (2004) 39-46.

DOI: 10.1016/s0257-8972(03)00794-1

[7] J. Zhang, H. Lv, G. Cui, Z. Jing, C. Wang, Effects of bias voltage on the microstructure and mechanical properties of (Ti, Al, Cr)N hard films with N-gradient distributions, Thin Solid Films, 519(15) (2011) 4818-4823.

DOI: 10.1016/j.tsf.2011.01.036

[8] C. Mitterbauer, W. Grogger, P. Wilhartitz, F. Hofer, Electron-irradiation damage in chromium nitrides and chromium oxynitride thin films, Micron 37(5) (2006) 385-388.

DOI: 10.1016/j.micron.2006.01.006

[9] L. Wu, J. Gao, Z. Liu, L. Liang, F. Xia, H. Cao, Thermal aging characteristics of CrNxOy solar selective absorber coating for flat plate solar thermal collector applications, Sol. Energy Mater. Sol. Cells, 114 (2013) 186-191.

DOI: 10.1016/j.solmat.2013.03.005

[10] Y. Feng, J. Zhang, Investigation of Microstructure and Mechanical Properties of (CrTiNb)N Films, Adv. Mater. Res. 287-290 (2014) 808-811.
