An Integrated Virtual Tool Chain for the Simulation of the Manufacturing Process of a Composite Tidal Blade

Abstract:

Within the European research project ECOMISE advanced process simulation methods have been developed. Existing Software tools like RTMWorx and NX CAE have been extended in their capabilities and interface have been developed between them to have a direct data communication. In the present case a manufacturing process of a tidal blade was used to test and validate the development. In RTMWorx a new 3D solution was developed and an a import interface to read direct a structural model from NX with all related information’s like geometry, mesh and layup. The interface reads the ply information’s and calculates resulting permabilities for the layup. In NX CAE also interfaces and mapping algorithm have been developed to read information’s like filling factors from RTMWorx. In combination with the new functionalities to simulate curing, process induced deformation and residual stresses the virtual process chain enabling a complete analysis of the whole manufacturing process starting from a initial design with capabilities on draping including direct ply contour creation, infusion, curing and analysis of process induced deformation.

• Periodical: Key Engineering Materials (Volume 742)
• Pages: 705-713
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.742.705
• Online since: July 2017
• Authors: Christian Brauner*, Frédéric Pascon, Tom van Eekelen, Maarten Bach, Arjen Kolovaar, Arne Breede
• Keywords: Composite, Composite Materials, Finite Element, Flow Simulation, Manufacturing Process Simulation, Process Induced Deformation, Process Induced Stress, Thermo-Elastic, Viscoelastic

References

[1] Dix et al., NAFEMS World Congress 2013, ISBN 978-1-874376-91-0, Salzburg, Austria, 53.

[2] Wille et al., NAFEMS World Congress 2013, ISBN 978-1-874376-91-0, Salzburg, Austria, 85.

[3] Kärger et al., NAFEMS World Congress 2013, ISBN 978-1-874376-91-0, Salzburg, Austria, 111.

[4] Brauner et al., J. of Composite Materials, 2015 Vol. 49 (4), 387-402.

[5] C. Brauner, T. B. Block, H. Purol, A. S. Herrmann, Microlevel manufacturing process simulation of carbon fiber/epoxy composites to analyze the effect of chemical and thermal induced residual stresses, Journal of Composite Materials Volume 46 Issue 17, August (2012).

DOI: 10.1177/0021998311430157

[6] C. Brauner, S. Bauer, A. S. Herrmann, Analysing process-induced deformation and stresses using a simulated manufacturing process for composite multispar flaps, Journal of Composite Materials, published online before print February 6, 2014, doi, 10. 1177/0021998313519281.

DOI: 10.1177/0021998313519281

[7] C. Brauner, P. Soprano, A. S. Herrmann, D. Meiners, Cure-dependent thermo-chemical modelling and analysis of the manufacturing process of an aircraft composite frame, Journal of Composite Materials, published online before print March 25, 2014, doi, 10. 1177/00219983145277777.

DOI: 10.1177/0021998314527777

[8] C. Brauner, G.C. Pereira, A. S. Herrmann, Effects of fabric-based unbalances on process-induced distortions of composite materials, Journal of Composite Materials 0021998314533365, first published on May 16, 2014 doi: 10. 1177/002199831453336.

DOI: 10.1177/0021998314533365

[9] C. Brauner, T. Frerich, A. S. Herrmann Cure-dependent thermomechanical modelling of the stress relaxation behaviour of composite materials during, Journal of Composite Materials, first published July 2016, DOI: 10. 1177/0021998316656924.

DOI: 10.1177/0021998316656924

[10] Kamal et al., Polymer Engineering and Science, 1973 Vol. 13, 59-64.

[11] Lee et al., Polymer Engineering and Science, 1992 Vol. 32 (15), 1037-1046.

[12] Lee et al., J. Composite Materials, 1982 Vol. 16, 510-520.

[13] Zocher et al., Int. J. Num. Meth. Engng., 1997 Vol. 40, 2267-2288.

[14] Hashin, J. Mech. Phys. Sol., 1965 Vol. 13, 119-134.

[15] Hill, J. Mech. Phys. Sol., 1965 Vol. 13, 213-222.

[16] C. Brauner, Analysis of process induced distortions and residual stresses in composite structures, 2013, Herausgeber A. S. Herrmann, Logos Verlag Berlin, ISBN 978-3-8325-3528-5, Science Report Nr 8.
