An Experimental Study on the Structural Behavior of Water and Wastewater Supply GFRP Pipe

Abstract:

In this paper, the results of experimental and analytical investigations pertaining to the structural behavior of glass fiber reinforced polymer plastic (GFRP) pipes are presented. GFRP is assumed as an orthotropic material. Mechanical properties along the longitudinal and hoop direction of the pipes are determined by the tension and compression tests. The parallel plate loading tests for the GFRP pipes were conducted to findthe relation between load and ring deflection. Inaddition, the finite element analysis (FEA) for the GFRP pipes was conducted using the material properties obtained from test in the study. The numerical results obtained by the finite element method show good agreement with the parallel plate loading test results for GFRP pipes.

• Periodical: Key Engineering Materials (Volume 753)
• Pages: 65-70
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.753.65
• Online since: August 2017
• Authors: Sun Hee Kim, Soon Jong Yoon, Won Chang Choi*
• Keywords: FEA, GFRP, Mechanical Characteristic, Parallelplate Loading Test, Ring Deflection

References

[1] A. Marston, The Theory of External Loads on Closed Conduits in the Light of the Latest Experimental, J. Civil Eng. 9 (1930) 137-170.

[2] R. K. Watkins, L. R. Anderson, Structural Mechanics of Buried Pipes, CRC Press, New York (2000).

[3] J. S. Park, A Study on the Ring Deflection Limitation of Buried Flexible Pipes, Ph.D. Thesis, Hongik University, Seoul (2011).

[4] E. J. Lee, Mechanical Properties and Structural Behavior of GRP Composite Pipes for Water Supply and Drainage, Master Thesis, Hongik University, Seoul (2008).

[5] H. Saadatmanesh, M. Tavakkolizadeh, D. Mostofinejad, Environmental Effects on Mechanical Properties of Wet Lay-Up Fiber-Reinforced Polymer, Technical paper, ACI Mater. J. 107-M31 (2010) 267-274.

DOI: 10.14359/51663755

[6] B. B. Lee, An Experimental Investigation on the Structural Behavior of GFRP Pipes, Master Thesis, Hongik University, Seoul (2009).

[7] KS M ISO 527-4, Plastics-Determination of Tensile Properties-Part 4: Test Conditions for Isotropic and Orthotropic Fibre-Reinforced Plastic Composites, Korean Agency for Technology and Standards (2012).

DOI: 10.3403/30409901

[8] ISO 527-4, Plastics-Determination of Tensile Properties-Part 4: Test Conditions for Isotropic and Orthotropic Fibre-Reinforced Plastic Composites, International Organization for Standardization (1997).

DOI: 10.3403/30409901

[9] KS M ISO 8521, Plastics Piping Systems-Glass-Reinforced Thermosetting Plastics (GRP) Pipes-Determination of the Apparent Initial Circumferential Tensile Strength, Korean Agency for Technology and Standards (2004).

DOI: 10.3403/01355061u

[10] ISO 10466, Plastics Piping Systems-Glass-Reinforced Thermosetting Plastics (GRP) Pipes-Test Method to Prove the Resistance to Initial Ring Deflection, International Organization for Standardization (1997).

DOI: 10.3403/00902674u

[11] KS M ISO 9969, Thermoplastics Pipes-Determination of Ring Stiffness, Korean Agency for Technology and Standards (2016).
