Accounting for the Flexibility of Beam-Column Joints within New Zealand Steel Moment-Resisting Frame Structures

Abstract:

In New Zealand there currently appears to be no simplified, effective method of analysing the rotational stiffness of beam-column joints in steel moment resisting frame structures. Many practicing engineers use simplified design tables to detail beam-column joints for strength requirements, without accounting for the flexibility of joints. This tends to underestimate the flexibility of structures and hence the drifts they undergo in wind and earthquake events. To permit improved consideration of beam-column joint stiffness in a simplified manner, this work adapts the European component method to develop a series of tables that practitioners could look up to quickly identify beam-column joint stiffness values. The potential use for such stiffness values is highlighted by examining the impact of joint flexibility on the drifts expected in a 4-storey steel MRF subject to 1 in 500 year return period earthquake loading.

• Periodical: Key Engineering Materials (Volume 763)
• Pages: 182-188
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.763.182
• Online since: February 2018
• Authors: Lilliana Wiles, Jonathan Pethybridge, Timothy John Sullivan*
• Keywords: Beam-Column Joint, Rotational Stiffness, Steel Moment-Resisting Frame

References

[1] NZS 1170. 5: 2004 Structural Design Actions, Part 5: Earthquake Actions-New Zealand. Standards New Zealand, New Zealand (2004).

[2] NZS 3404. Part1: 1997 Steel Structures Standard. Standards New Zealand, New Zealand (1997).

[3] C. Hyland, G.C. Clifton, & New Zealand Heavy Engineering Research Association, Structural Steelwork Connections Guide, New Zealand Heavy Engineering Research Association (1999).

[4] N. Krishnamurthy, D.E. Graddy, Correlation between 2- and 3-Dimensional Finite Element Analysis of Steel Bolted End-Plate Connections, " Computers & Structures, Vol. 6, No. 4-5 (1976), pp.381-389.

DOI: 10.1016/0045-7949(76)90016-x

[5] H. Augusto, J.M. Castro, C. Rebelo, and L.S. da Silva, Characterising partial-strength joints using finite element analysis, in: T.J. Sullivan and G. O'Reilly (Editors), Characterising the Seismic Behaviour of Steel Beam-Column Joints for Seismic Design" Research Report EUCENTRE 2014/01, EUCENTRE Press, Pavia, Italy (2014).

[6] CEN, European Committee for Standardization, (2005). Eurocode 3: Design of steel structures - Part 1-8: Design of joints.

[7] G. Della Corte, G. Terracciano, G. Di Lorenzo and R. Landolfo Charactierising bolted end-plate beam-column joints using the component method, in: T.J. Sullivan and G. O'Reilly (Editors), Characterising the Seismic Behaviour of Steel Beam-Column Joints for Seismic Design" Research Report EUCENTRE 2014/01, EUCENTRE Press, Pavia, Italy (2014).

DOI: 10.1155/2018/9689453

[8] SeismoSoft srl, SeismoStruct, SeismoSoft Ltd., Inc., Earthquake Engineering Software Solutions, Greece, [online]. Available (2017) from URL: http: /www. seismosoft. com.
