Joining by Forming of Tubes to Sheets with Counterbored Holes

Abstract:

This paper presents a new joining by forming process for connecting tubes to sheets. The process consists of forming an annular flange with rectangular cross section by partial sheet-bulk of the tube wall thickness and performing the mechanical interlock by upsetting the free tube end against a flat-bottomed (counterbored) sheet hole. The presentation identifies the variables and the workability limits of the process and includes an analytical model to assist readers in the design of the new joints. The new proposed joining by forming process and the corresponding analytical model are validated by experimentation and numerical simulation using finite element analysis. The process allows connecting tubes to sheets made from dissimilar materials at room temperature, avoids the utilization of addition materials or adhesives and produces joints that are easy to disassembly at the end of live, allowing recyclability of the tubes and sheets.

• Periodical: Key Engineering Materials (Volume 767)
• Pages: 421-428
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.767.421
• Online since: April 2018
• Authors: Luis Alves, Rafael M. Afonso, Carlos Silva, Paulo A.F. Martins*
• Keywords: Experimentation, Finite Element Modelling (FEM), Joining by Forming, Sheets, Tubes

References

[1] K. Mori, N. Bay, L. Fratini, F. Micari, A.E. Tekkaya, Joining by plastic deformation, CIRP Annals - Manufacturing Technology 62 (2013) 673–694.

DOI: 10.1016/j.cirp.2013.05.004

[2] L.M. Alves, E.J. Dias, P.A.F. Martins, Joining sheet panels to thin-walled tubular profiles by tube end forming, Journal of Cleaner Production 19 (2011) 712-719.

DOI: 10.1016/j.jclepro.2010.12.014

[3] I. Sizova, A. Sviridov, M. Bambach, Avoiding crack nucleation and propagation during upset bulging of tubes, International Journal Materials Forming 10 (2017) 443-451.

DOI: 10.1007/s12289-016-1292-9

[4] L.M. Alves, R.M. Afonso, C.M.A. Silva, P.A.F. Martins. Joining tubes to sheets by boss forming and upsetting, Journal of Materials Processing Technology (2017) (submitted).

DOI: 10.1016/j.jmatprotec.2017.10.047

[5] M. Merklein, J.M. Allwood, B.A. Behrens, A. Brosius, H. Hagenah, K. Kuzman, K. Mori, A.E. Tekkaya, A. Weckenmann, Bulk forming of sheet metal, CIRP Annals - Manufacturing Technology 61 (2012) 725–745.

DOI: 10.1016/j.cirp.2012.05.007

[6] C.V. Nielsen, W. Zhang, L.M. Alves, N. Bay, P.A.F. Martins, Modelling of Thermo-Electro-Mechanical Manufacturing Processes with Applications in Metal Forming and Resistance Welding, Springer-Verlag, London, (2013).

DOI: 10.1007/978-1-4471-4643-8
