Research on the Experimental Method of Measuring Internal Stress of Polymer Sheet Product by Lamb Wave

Abstract:

The internal stress of the polymer sheet could change when the process condition and structure characteristics of the polymer chain is different. As Lamb wave has different damping when passing through the anisotropic media, fixed distance irradiation and amplitude sampling is used to analyze the amplitude attenuation in different regions, so as to determine the stress distribution in different regions of the sheet. The test results and the simulation results with Moldflow are consistent, so it is feasibility to measure internal stress of polymer sheet product through by Lamb wave.

• Periodical: Key Engineering Materials (Volume 773)
• Pages: 106-110
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.773.106
• Online since: July 2018
• Authors: Hong Xu, Ning Hu, Huang Yao*, Da Ming Wu, Ying Liu, Yao Lu Liu
• Keywords: Amplitude Attenuation, Internal Stress, Polymer Sheet Products, Ultrasonic Lamb Wave
