Effect of Thermal Treatments on the Schottky Contact between Polycrystalline PbS Thin Film and Gold

Abstract:

Electrical characteristics of semiconductor to metal (S-M) contacts i.e. Schottky contacts, play a vital role towards the performance of the device. The formation of a Schottky contact requires precise thermal treatment, which also affects the electrical characteristic of the junction. In present study, a thin layer of polycrystalline lead sulfide (PbS) was deposited on quartz substrate using chemical bath technique. Metallic electrodes of aluminum and gold were deposited on the each side of the semiconductor film by thermal evaporation method. The aluminum and gold films were 10 nm and 200 nm thick, respectively. Latter, the substrates were thermally treated in air for various durations and the effect of the thermal treatments was evaluated by I-V measurements. It was found that anomalies in the electrical behavior of the S-M contacts were mitigated with the treatments. A change from 0.1 x 10^-6A to 0.4 x 10^-6A in saturation current was observed. Similarly, the ideality factor (at V_th<<V_d) of the S-M contact was 12 on pristine PbS, while it reduced to 2.7 after the thermal treatment, which indicates an improved Schottky contact.

• Periodical: Key Engineering Materials (Volume 778)
• Pages: 230-235
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.778.230
• Online since: September 2018
• Authors: Abu Bakar*, Muhammad Mansoor, Muhammad Muneeb Asim, Shaheed Khan
• Keywords: Gold Schottky Contacts, Ideality Factor, IV Testing, PbS Semiconductor Thin Films, Saturation Current

References

[1] R.G. Streetman, S. Banerjee., Solid State Electronic Devices, 5th ed., Prentice Hall, NJ, (2000).

[2] D.A. Neamen, Semiconductor Physics and Devices: Basic Principles 3rd ed., McGraw-Hill., Boston, (2003).

[3] S. Wang, Fundammrals of Semiconductor: Theory and Devices Physics, Englewoud Cliffi., NJ: Prentice Hall, (1989).

[4] J. Nordstrom, M. Johansson, A. S´anchez Nogueron, E. Calleja, M. Boisen, Investigation of the bond strength between the photo-sensitive polymer SU-8 and gold., Microelectron. Engin., 78-79 ( 2005) 152–157.

DOI: 10.1016/j.mee.2004.12.021

[5] S. Zaman, S.K. Mehmood, M. Mansoor, M.M. Asim, Effect of lead ion concentration on the structural and optical properties of nano-crystalline PbS thin films, IOP Conf. Ser. Mat. Sci. Engin., 60 (2014) 012057.

DOI: 10.1088/1757-899x/60/1/012057

[6] S. Gholami, M. Khakbaz, Measurement of I-V characteristics of a PtSi/p-Si schottky barrier diode at low temperature, Electron. Comm. Engin., 5 (2011) 389-397.

[7] E.H. Rhoderick, R.H. Williams, Metal Semiconductor Contacts, 2nd ed., Clarendon Press, Oxford, (1988).

[8] A. OS, T. Rington, Electrical transport at a non-ideal CrSi2-Si junction, Sol. State Electron., 44 (2000) 178-189.

[9] V.L. Rideout, A Review of theTheory,Technology and Applications of Mctal-Semiconductor Rectifiers, Th.Sol. Fil., 3 (1978) 261-291.
