A Computational Simulation of Martensitic Transformation in Polycrystal TRIP Steel by Crystal Plasticity FEM with Voronoi Tessellation

Abstract:

TRIP steel shows excellent mechanical properties such as greatly high strength, ductility and toughness by means of the appropriate combination of the strain-induced martensitic transformation (SIMT) behavior and the deformation behavior of each phase at crystal scale. In the past, the effect of grain size in the austenite on the deformation behavior of TRIP steel is investigated by introducing the grain size into a generalized model for the kinetics of SIMT. In order to validate the size-dependent kinetics modelling, it is necessary to simulate the deformation and SIMT behavior of the polycrystalline for the different grain size at the crystal scale. This study focuses on an investigation of SIMT behavior in polycrystalline TRIP steel by finite element simulation. The constitutive formula for monocrystalline TRIP steel including transformation strain in each variant system derived on the basis of the continuum crystal plasticity theory is applied. For the polycrystalline model, Voronoi tessellation is employed. The deformation behavior with a patterning process of martensitic phase in two different numbers of grains with initial crystal orientations for describing the deformation-related length scale is simulated under plane strain condition with two planar slip systems by a cellular automata approach.

You might also be interested in these eBooks

Advances in Engineering Plasticity and its Application IX

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 794)

Pages:

71-77

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.794.71

Citation:

Cite this paper

Online since:

February 2019

Authors:

Truong Duc Trinh, Takeshi Iwamoto*

Keywords:

Cellular Automata, Crystal Plasticity, Finite Element Method (FEM), Pattern Formation, Strain-Induced Martensitic Transformation, TRIP Steel, Voronoi Tessellation

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] J. S. Bowles, J. K. Mackenzie, The crystallography of martensite transformations I, Acta Metall. 2 (1954) 129-137.

Google Scholar

[2] C. M. Wayman, Introduction to the crystallography of martensitic transformations, Macmillan, (1964).

Google Scholar

[3] T. Iwamoto, T. Tsuta, Computational simulation of the dependence of the austenitic grain size on the deformation behavior of TRIP steels, Int. J. Plast. 16 (2000) 791-804.

DOI: 10.1016/s0749-6419(99)00079-0

Google Scholar

[4] M. Tokuda, M. Ye, M. Takakura, P. Sittner, Thermomechanical behavior of shape memory alloy under complex loading conditions, Int. J. Plast. 15 (1999) 223-239.

DOI: 10.1016/s0749-6419(98)00066-7

Google Scholar

[5] R. J. Asaro, Crystal Plasticity, J. Appl. Mech. 50 (1983) 921-934.

Google Scholar

[6] K. Gall, T. J. Lim, D. L. McDowell, H. Sehitoglu, Y. I. Chumlyakov, The role of intergranular constraint on the stress-induced martensitic transformation in textured polycrystalline NiTi, Int. J. Plast. 16 (2000) 1189-1214.

DOI: 10.1016/s0749-6419(00)00007-3

Google Scholar

[7] P. Thamburaja, L. Anand, Polycrystalline shape-memory materials: effect of crystallographic texture, J. Mech. Phys. Solids. 49 (2001), 709-737.

DOI: 10.1016/s0022-5096(00)00061-2

Google Scholar

[8] D. D. Tjahjanto, S. Turteltaub, A. S. J. Suiker, Crystallographically based model for transformation-induced plasticity in multiphase carbon steels, Continuum Mech. Thermodyn. 19 (2008) 399-422.

DOI: 10.1007/s00161-007-0061-x

Google Scholar

[9] S. L. Wong, M. Madivala, U. Prahl, F. Roters, D. Raabe, A crystal plasticity model for twinning- and transformation-induced plasticity, Acta Mater. 118 (2016) 140-151.

DOI: 10.1016/j.actamat.2016.07.032

Google Scholar

[10] T. Iwamoto, T. Tsuta, Finite element simulation of martensitic transformation in singlecrystal TRIP steel based on crystal plasticity theory with cellular automata approach, Key Eng. Mater. 274-276 (2004) 679-684.

DOI: 10.4028/www.scientific.net/kem.274-276.679

Google Scholar

[11] Y. Kitajima, N. Sato, K. Tanaka, S. Nagaki, Crystal-based simulations in transformation thermomechanics of shape memory alloys, Int. J. Plast. 18 (2002) 1527-1559.

DOI: 10.1016/s0749-6419(02)00028-1

Google Scholar

[12] V. Levitas, Thermomechanical theory of martensitic phase transformations in inelastic materials, Int. J. Solids Struct. 35(1998) 889-940.

DOI: 10.1016/s0020-7683(97)00089-9

Google Scholar

[13] D. Peirce, C. F. Shih, A. Needleman, A tangent modulus method for rate dependent solids, Comp. Struct. 18 (1984) 875-887.

DOI: 10.1016/0045-7949(84)90033-6

Google Scholar

[14] Z. Nishiyama, Martensitic transformation, first ed., Academic Press, New York, (1978).

Google Scholar
