Аpplication Development for the Evaluation of Penetration in Laser and Laser-Arc Hybrid Welding of Tee and Corner Joints

Abstract:

Laser technologies deservedly take their place in modern mechanical engineering production. Using laser source for welding has already become common. However, the creation of critical welded constructions is impossible without extensive technological surveys, which can be greatly simplified by using a computational experiment. To achieve this goal, special programs are usually used. That can be unjustified difficult and thereby awkward for technological practice. The article describes an application built on the basis of a simplified model for calculating the temperature field for the cases of laser and laser-arc welding of internal fillet welds as well as single-sided T-joints and simultaneous double-sided welds. The results of calculations by the model and comparing them with experimental data have shown that it is sufficiently adequate for use in technological purposes. The developed application contemporaneously has a simple and intuitive interface, does not require significant computational resources and can be used for quick preliminary estimation of the result of welding for the selected type of weld.

• Periodical: Key Engineering Materials (Volume 822)
• Pages: 381-388
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.822.381
• Online since: September 2019
• Authors: Ilya Nikolaevich Udin*, A.A. Voropaev, A. Unt
• Keywords: Corner Joint Welding, Laser Welding, Laser-Arc Hybrid Welding, Software, T-Joint Welding

References

[1] Lopota V, Turichin G, Tzibulsky I, Valdaytzeva E, Kreutz E, Schulz W, Theoretical description of dynamic phenomena in laser welding with deep penetration,, Proceedings of SPIE - The International Society for Optical Engineering (1999) 3688 98-107.

DOI: 10.1117/12.337492

[2] Turichin G, Valdaytseva E, Tzibulsky I, Lopota A, Velichko O, Simulation and technology of hybrid welding of thick steel parts with high power fiber laser, Physics Procedia (2011) 12(PART 1) 646-655.

DOI: 10.1016/j.phpro.2011.03.081

[3] Turichin G, Klimova O, Valdaytseva E, Effect of peculiarities of heat transfer, diffusion and phase transformation on joint formation during welding of dissimilar materials by high power fiber laser,, Physics Procedia (2014) 56(C) 566-575.

DOI: 10.1016/j.phpro.2014.08.044

[4] Turichin G, Tsibulskiy I, Kuznetsov M, Akhmetov A, Mildebrath M, Hassel T, Influence of the Gap Width on the Geometry of the Welded Joint in Hybrid Laser-Arc Welding,, Physics Procedia (2015) 78 14-23.

DOI: 10.1016/j.phpro.2015.11.013

[5] Turichin G, Kuznetsov M, Sokolov M, Salminen A, Hybrid Laser Arc Welding of X80 Steel: Influence of Welding Speed and Preheating on the Microstructure and Mechanical Properties,, Physics Procedia (2015) 78 35-44.

DOI: 10.1016/j.phpro.2015.11.015

[6] Turichin G, Tsibulsky I, Somonov V, Kuznetsov M, Akhmetov A, Laser-TIG Welding of Titanium Alloys,, IOP Conference Series: Materials Science and Engineering (2016) 142(1).

DOI: 10.1088/1757-899x/142/1/012009

[7] Turichin G, Tsibulskiy I, Kuznetsov M, Akhmetov A, Klimova-Korsmik O Hybrid Laser-Arc Welding Tanks Steels,, IOP Conference Series: Materials Science and Engineering (2016) 125(1).

DOI: 10.1088/1757-899x/125/1/012002

[8] Turichin G, Kuznetsov M, Tsibulskiy I, Firsova A,Hybrid Laser-Arc Welding of the High-Strength Shipbuilding Steels: Equipment and Technology,, Physics Procedia (2017) 89 156-163.

DOI: 10.1016/j.phpro.2017.08.005

[9] Zemlyakov E, Babkin K, Klimova O, Turichin G, Elkin V, Remotely controlled laser welding of tube-to-tube plate joints in the manufacture of heat exchangers,, Welding International (2016) 30(6) 479-483.

DOI: 10.1080/09507116.2015.1090177

[10] E A Valdaytseva and G. A. Turichin СAE-system LaserCAD for laser welding,.

[11] Bappa Acherjee, Hybrid laser arc welding: State-of-art review,, Optics & Laser Technology, Volume 99, 1 February 2018, Pages 60-71.

DOI: 10.1016/j.optlastec.2017.09.038

[12] E A Valdaytseva and I N Udin, Determination of the heat source parameters for the case of simultaneous two-sided laser-arc welding of extended T-joints, 2018 J. Phys.: Conf. Ser. 1109 012009.

DOI: 10.1088/1742-6596/1109/1/012009

[13] I A Tsibulskiy, A D Akhmetov, R S Korsmik, A A Voropaev,∗, R V Mendagaliyev, A D Eremeev, The influence of the gap size on the formation of a welded joint in hybrid laser-arc welding of angular joints and T-joints, 2018 J. Phys.: Conf. Ser. 1109 012033.

DOI: 10.1088/1742-6596/1109/1/012033
