On the Strength Weakening Effect of Stiffening Ribs in the Design of Machine Components

Abstract:

The bending stress in beams may often be reduced by adding material to the cross section. In some paradoxical cases, however, the bending stress increases by adding material from zones far away, or close to, the neutral axis. Similarly, the bending stress of rectilinear or curved beams may often be reduced by adding ribs to the initial beam section. However, such ribs may sometimes cause a both undesired and unexpected stress increase, although they still produce a beneficial stiffening effect. The aim of this paper is twofold: a) to examine this unexpected result within the context of the paradoxical behaviour of some known beam sections, and especially of a recently noted paradox; b) to provide a preliminary rule of thumb for the mechanical design of ribs sometimes added to the outer surface of an eye, with particular regard to the small end of a connecting rod.

• Periodical: Key Engineering Materials (Volume 827)
• Pages: 240-245
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.827.240
• Online since: December 2019
• Authors: Antonio Strozzi*, E. Bertocchi, V. Mangeruga
• Keywords: Design Optimization, Mass Reduction, Paradox of Mechanics, Stiffening Rib, Stress

References

[1] Navier, CLMH. De la résistance des corps solides. 3 ed. avec des notes et des appendices par M. Barre de Saint–Venant. Paris: Dunod, 1864, pp.95-99.

[2] Strozzi, A., Bertocchi, E., Mantovani, S., 2018. A paradox in curved beams. Preprint Proc. IMechE Part C: J Mech. Engng Sci,.

DOI: 10.1177/0954406218797980

[3] Timoshenko, S. Strength of Materials. New York: John Willey and Sons, 1930, pp.98-101.

[4] Barber, J.R. Intermediate Mechanics of Materials (Vol. 175). Springer Science & Business Media, 2010, p.491.

[5] Boresi, A.P., Schmidt, R.J., Sidebottom, O.M., 1993. Advanced Mechanics of Materials, Wiley, N.Y., p.368.

[6] Leopardi, L. Strozzi, A. 2018. Two extensions towards practical applications of a paradox in curved beams. Under review.

DOI: 10.1016/j.procir.2019.04.296

[7] Leyer, A. Machine design, 2012, Springer Science & Business Media, p.81.

[8] Strozzi, A., De Bona, F. 2005. Hoop stresses in the con-rod small end. Proceedings of the Institution of Mechanical Engineers, Part D: Journal of Automobile Engng, 219(11), pp.1331-1345.

DOI: 10.1243/095440705x34973

[9] Strozzi, A., Baldini, A., Giacopini, M., Bertocchi, E., Mantovani, S., 2016. A repertoire of failures in connecting rods for internal combustion engines, and indications on traditional and advanced design methods. Engng Failure Analysis, 60, pp.20-39.

DOI: 10.1016/j.engfailanal.2015.11.034

[10] Strozzi, A., Baldini, A., Giacopini, M., Bertocchi, E., Mantovani, S., 2018. A repertoire of failures in gudgeon pins for internal combustion engines. Engng Failure Analysis, 87, pp.22-48.

DOI: 10.1016/j.engfailanal.2018.02.004

[11] Strozzi, A. Foundations of Machine Design. Bologna, Italy; Pitagora, 2016 (In Italian).
