The Formation of Contrasting Nanofilms on a Metal Surface for Bar Coding

Abstract:

Laser marking is a universal method of applying information to the products surface. Colored oxide films form on metal surface during a thermal exposure. The degree of steel heating influences the film thickness. Corrosion-resistant steel AISI 304 samples were laser-marked with a MiniMarker 2-20A4 precision laser complex. The contrast of the barcodes on a metal area depends on the surface roughness and the chemical composition of the steel. Fe₂O₃, Fe₃O₄ oxides forms the greatest contrast. RGB indicators are used to assess contrast. Study results may be applicable to increase the QR code contrast thereby contributing to the improvement of laser marking technology while preserving economic efficiency.

• Periodical: Key Engineering Materials (Volume 854)
• Pages: 97-102
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.854.97
• Online since: July 2020
• Authors: Darina A. Konchus*, Aleksei V. Sivenkov
• Keywords: Contrast Assessment, Laser Marking, Oxide Nanofilms

References

[1] O. Y. Ganzulenko, A. P. Petkova, Selection of alloying elements in steels for obtaining images full range of colors on the surface of the products by means of a pulsed laser radigation, J. of Mining Institute 209 (2014) 216–219.

[2] A. E. Efimov, D. Y. Timofeev, V. V. Maksarov, Modeling dynamic processes at stage of formation of parts previously subjected to high-energy laser effects, IOP Conf. Ser.: Materials Science and Engineering 327(2) (2018) 22026.

DOI: 10.1088/1757-899x/327/2/022026

[3] M. Afonkin, E. Larionova, S. Gornyi, Analysis of laser engraving complexes technological Capabilities, Photonics 5 (2010) 4–11.

[4] A. V. Sivenkov, K. I. Konovalov, E. I. Zverkova, Influence laser marking on structure and properties steel, International Scientific Review 11 (2016) 38–40.

[5] G. G. Popov, V. I. Bolobov, Study of factors enabling initiation and behavior of grooving corrosion, E3S Web of Conferences 121 (2019) 03004.

DOI: 10.1051/e3sconf/201912103004

[6] V. V. Maksarov, A. I. Keksin, Forming conditions of complex-geometry profiles in corrosion-resistant materials, IOP Conf. Ser.: Earth Environ. Sci. 194 (2018) 062016.

DOI: 10.1088/1755-1315/194/6/062016

[7] E. I. Pryakhin, O. Y. Ganzulenko, A. P. Petkova, Development of polygraphic program-controlled hardware system for applying high-density coding on surface of products made from varied materials, IOP Conf. Ser.: Earth and Environmental Science 194(4) (2018) 042020.

DOI: 10.1088/1755-1315/194/4/042020

[8] E. I. Pryakhin, E. V. Larionova, E. A. Zakharenko, Creating and approbation of the hardware and software complex for information fields application on the surface of products, J. of Mining Institute 209 (2014) 234–238.

[9] V. P. Veiko, G. V. Odintsova, Yu. Yu. Karlagina, Ya. M. Andreeva, E. I. Ageev, R. M. Yatsuk, Research of the entrance angle effect on the reflectance spectra of the stainless steel surface oxidized by pulsed laser radiation, Scientific and technical journal of information technologies, mechanics and optics 16(3) (2016) 422–427.

DOI: 10.17586/2226-1494-2016-16-3-422-427

[10] D. N. Antonov, A. A. Burtsev, O. Y. Butkovskii, Coloration of a metal surface under pulsed laser irradiation. Technical Physics, The Russian Journal of Applied Physics 84(10) (2014) 1503–1505.

DOI: 10.1134/s1063784214100077

[11] V. V. Maksarov, A. D. Khalimonenko, J. J. Olt, Effect of porosity on the performance of cutting ceramics, Agronomy Research, 1(14) (2016) 1043–1052.

[12] A. V. Sivenkov, Research of the properties of nickel coatings deposited from low-melting melts, J. of Engineering Science and Technology (St. Petersburg polytechnic university), 3(84) (2009) 119–123.

[13] A. D. Khalimonenko, K. P. Pompeev, D. Y. Timofeev, Dimensional analysis of the manufacturing processes of axisymmetric parts, IOP Conference Series: Materials Science and Engineering 560(1) (2019) 12144.

DOI: 10.1088/1757-899x/560/1/012144

[14] D. A. Konchus, A. V. Sivenkov, E. I. Priahin, O. S. Chirkova, Assessment of laser marking contrast with profilometer, IOP Conf. Ser.: Earth and Environmental Science 194(4) (2018) 1–6.

DOI: 10.1088/1755-1315/194/4/042022
