Design and Simulation of Metal Oxide Gas Sensor for Breath Analyzer Application

Abstract:

Metal oxide semiconductor has been widely used for breath analyzer applications. In this work, Acetone gas is the target gas as it an important breath marker for diabetes disease. Among the different p-type metal oxide nanostructures, Nickel oxide nanospheres are used as the sensing material as it is a promising candidate for Acetone sensing. The variation of resistance of the sensing material with the concentration of the target gas was analyzed. As Acetone is a reducing gas, the resistance of the sensing layer was found to increase when the sensing layer was exposed to the target gas. The simulation was done using COMSOL Multiphysics.

• Periodical: Key Engineering Materials (Volume 877)
• Pages: 96-101
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.877.96
• Online since: February 2021
• Authors: M.S. Lekshmi*, K. Arun, K.J. Suja
• Keywords: Acetone, Breath Analyzer, Gas Sensor, Micro-Hotplate, Nickel Oxide

References

[1] Faglia G., Comini E. and Pardo M., Micromachined gas sensors for environmental pollutants,, Journal of microsystem technologies, Vol. 6, No. 16, (1999), pp.54-59.

DOI: 10.1007/s005420050175

[2] Dieter K (2001) Function and applications of gas sensors. J Phys D Appl. Phys 34(19): R125.

[3] Fine GF, Cavanagh LM, Afonja A, Binions R Metal Oxide Semi-Conductor Gas Sensors in Environmental Monitoring. Sensors (Basel, Switzerland) 10(6), (2010), p.5469–5502.

DOI: 10.3390/s100605469

[4] Zhang J, Qin Z, Zeng D, Xie C, Metal-oxide semiconductor based gas sensors: screening, preparation, and integration. PhysChem 19(9), (2017), pp:6313–6329.

DOI: 10.1039/c6cp07799d

[5] Hotovy I, Huran J Spiess L, Hascik S, Rehacek V. Preparation of nickel oxide thin films for gas sensors applications, Sensors & Actuators B: Chemical, 57, (1999),147-152.

DOI: 10.1016/s0925-4005(99)00077-5

[6] Justin O, Meher SK, Rao GR, Tuning capacitance behavior of NiO using anionic, cationic and nonionic surfactants y hydrothermal synthesis, Journal of Physical Chemistry, 114, (2010), 5203-5210.

DOI: 10.1021/jp9097155

[7] Mallick P, Sahoo CS, Mishra NC, Structural and Optical characterization of NiO nanoparticles synthesized by sol-gel route, AIP conf Proc, 1461, (2012), 229-232.

DOI: 10.1063/1.4736893

[8] Alagiri M, Ponnusamy S, Muthamizhchelvam C, Synthesis and Characterization of NiO nanoparticles by sol-gel method, Journal of Matter Science: Matter Electron, 23, (2012), 728-732.

DOI: 10.1007/s10854-011-0479-6

[9] Briand D., Krauss A. and van der Schoot, Design and fabrication of high-temperature micro- hotplates for drop-coated gas sensors,, Journal of sensors and actuators, Vol. 68, No. 9(2000), pp.223-233.

DOI: 10.1016/s0925-4005(00)00433-0

[10] S.RoyMorrison, Selectivity in semiconductor gas sensors,, Sensors and Actuators, vol.12, pp.425-440,(1987).

DOI: 10.1016/0250-6874(87)80061-6

[11] G. Konvalina, H. Haick Sensors for breath testing: from nanomaterials to comprehensive disease detection Acc. Chem. Res., 47 (2014), pp.66-76.

DOI: 10.1021/ar400070m

[12] S.V. Ryabtsev, A.V. Shaposhnick, A.N. Lukin, E.P. Domashevskaya Application of semiconductor gas sensors for medical diagnostics Sens. Actuators B: Chem., 59 (1999), pp.26-29.

DOI: 10.1016/s0925-4005(99)00162-8

[13] W. Ping, T. Yi, X. Haibao, S. Farong A novel method for diabetes diagnosis based on electronic nose Biosens. Bioelectron., 12 (1997), pp.1031-1036.

DOI: 10.1016/s0956-5663(97)00059-6

[14] W. Tan, J. Tan, L. Fan, Z. Yu, J. Qian, X. Huang Fe2O3-loaded NiO nanosheets for fast response/recovery and high response gas sensor Sens. Actuators B: Chem., 256 (2018), pp.282-293.

DOI: 10.1016/j.snb.2017.09.187

[15] C. Di Natale, R. Paolesse, E. Martinelli, R. Capuano Solid-state gas sensors for breath analysis: a review Anal. Chim. Acta, 824 (2014), pp.1-17.

DOI: 10.1016/j.aca.2014.03.014

[16] Kumar H, Sing K K, Sood N, Kumar A, and Mittal R K, Design and Simulation of a Micro Hotplate for MEMS based integrated gas sensing system,, Sensors Applications Symposium (SAS) (2014).

DOI: 10.1109/sas.2014.6798942

[17] Velmathi. G, Ramshanker. N and Mohan. S, 2D Simulations and Electro-Thermal Analysis of Micro-Heater Designs Using COMSOLTM for Gas Sensor Applications,, COMSOL 2010, Bangalore, India.

[18] Hardeep Kumar, Anuj Kumar, K.K. Singh, NeeruSood, R.K. Mittal, Design and Simulation of a Micro Hotplate for MEMS based Integrated Gas Sensing System,, 2014 IEEE Sensors Applications Symposium, Queenstown, New Zealand, Feb. (2014).

DOI: 10.1109/sas.2014.6798942

[19] Lekshmi M S, Ravi Pamula, AkkellaKartik, Suja K J, Performance analysis of microhotplate based metal oxide nanowire gas sensor, 7th IEEE International Symposium on Next-Generation Electronics (ISNE 2018), Taiwan.

DOI: 10.1109/isne.2018.8394690
