Influence of the Steel Channel Shaped Shear Connectors on the Stability of the Simply Supported Steel Bridge without the Intermediate Bracing System in the Construction Stage

Abstract:

Steel bridge structure without intermediate bracing system (IBS) has been widely used in several countries and one of them is Japan. In this type of structure, the main steel girder is not reinforced by the stiffeners. The stiffness of the main girder is enhanced with steel plate directly welded to the top flange of the main girder, forming the “beams–system”. The reinforced concrete deck slab with the set of main girder and steel plate works compositely through steel shear connectors whose shape is C (channel) or I character. As for steel bridge structures, the main role of shear connectors is shear resistance between the concrete deck slab and steel girder plate in the exploitation stage. However, previous research has shown that the density of shear connectors influences on the stability as well as the stiffness of the bridge structure. Therefore, it has approved that this appurtenance is able to not only have the ability of shear resistance but also enhance the stiffness of the steel bridge structure which is particularly surveyed with the type of especial bridge structure – the steel bridge structure without IBS. Hence, the shear connectors in this kind of bridge structure are deliberately researched as an extra role in the construction stage. The following factors of the channel shape shear connectors would be researched for evaluating their impacting level on the stability of the special steel bridge structure: the properties (the length and the moment of inertia of the cross-section) and the density on the steel plate. Through the analysis of impacting level to the stability of three mentioned factors (the length and density of the shear connectors; the moment of inertia of the cross-section), the expected result is as following: 1) The minimum density of shear connectors is proposed. 2) The influence of the moment of inertia of the cross-section, the density, and the length on the stability is quite clear. 3) As for the economy, the optimal designed range among three factors is also suggested.

• Periodical: Key Engineering Materials (Volume 879)
• Pages: 151-168
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.879.151
• Online since: March 2021
• Authors: Van Khai Nguyen, Nghia Dai Van, Van Tuong Khanh Vo, Rin Anh Nguyen, Phuc Gia Nguyen, Chu An Le Huynh, Thi Ngoc Huynh*
• Keywords: Bridge Structure, Intermediate Bracing System, Shear Connector, Stability

References

[1] T.T.T. Nguyen, V.H. Mac, Behavior analysis of new type of girder bridges without intermediate beams, Vietnam Journal of Transport. (2015).

[2] A.R. Nguyen, L.T Pham and N.T Huynh, Surveying the overall instability of the steel girder bridge without intermediate bracing system for simply supported beam bridge during construction stage, Vietnam Journal of Construction. 12.2018 (2018) 32-36.

DOI: 10.4028/www.scientific.net/kem.879.151

[3] V.N Le, A.R Nguyen, L.T Pham and N.T Huynh, The study on the behavior of the simply supported beam steel bridge structure without the intermediate bracing system in the construction stages, CIGOS 2019, Innovation for Sustainable Infrastructure. (2019) 137-143.

DOI: 10.1007/978-981-15-0802-8_18

[4] W.A. Thornton, M.V. Holland, A. Aminmansour, C.J. Carter, Design examples, in: American Institute of Steel Construction (Eds.), AISC Shapes Database v15.1, the United States of America, (2019).

[5] G. Fredrick, B.V. Johnson, J.L. Hartmann, P.J. Bush, AASHTO LRFD Bridge Design Specifications, eighth ed., Washington, the United States of America, (2017).

[6] MIDAS Information Technology Co., Ltd, Analysis for civil structures, Linear buckling analysis, Korea, pp.163-180.

[7] 3E Steel Technology Engnineering Joint Stock Company, Profile of Luong Thuc Bridge, (2016).

[8] R.H. Myers, D.C. Montgomery, C.M. Anderson-Cook, Response surface methodology, in: D.J. Balding, N.A.C. Cressie, G.M. Fitzmaurice, G.H. Givens, H. Goldstein, G. Molenberghs, D.W. Scott, A.F.M. Smith, R.S. Tsay, S. Weisberg (Eds.), Two-level factorial designs, John Wiley & Sons Publishing Inc., Hoboken, New Jersey, Canada, 2016, pp.81-160.

[9] S. Allmeier, J Frenzel, S Schiefer, G Seidl, J Weber, Innovation in Verbundbrückenbau –Talbrücke Oberhartmannsreuth, Stahlbau. (2000) 707-713.

DOI: 10.1002/stab.200002560

[10] Information on https://www.pnsastech.com.ph/Bridge-Products.php.

[11] Information on https://usbridge.com/steel-bridge-structure/.

[12] Information on https://www.aisc.org/nsba/why-steel-bridges/.

[13] W.M.K. Roddis, Cross-frame diaphragm bracing of steel bridge girders, Washington, (2008).

[14] Nippon Steel and Sumikin Engineering Co., Ltd, Bridge Technology for Speedy Construction Low Price and High Quality.
