Dispersion of Flatness of the Machined Surface and Optimization of Cutting Conditions when Performing a Real Experiment of Face Milling of High-Hardness Steel

Abstract:

To study the face milling of hardened steel, the paper considers the chemical composition of the processed material, as well as metal-cutting, measuring equipment and tools. A full factorial experiment of face milling was carried out by the method of mathematical planning and matrices of levels of variation and planning of independent variables were compiled. The flatness of the samples was measured and the causes of plastic deformation were determined. To find an adequate mathematical model of flatness, a regression analysis was performed, and the correlation analysis revealed the closeness of the relationship between the variables under one-and two-factor influence on the response function. The hypersurfaces and lines of the function levels are projected, which made it possible to determine the optimal and effective cutting conditions graphically and analytically.

• Periodical: Key Engineering Materials (Volume 910)
• Pages: 17-23
• DOI: https://doi.org/10.4028/p-r5a610
• Online since: February 2022
• Authors: Igor Sedinin*, Vladimir Makarov, Michael V. Pesin, Sergey Nikitin
• Keywords: Correlation, Face Milling, Flatness, Full Factorial Experiment, Hardened Steel, Hypersurface, Levels Lines, Mathematical Model, Polyline Mesh

References

[1] V.T. Babkin, A.A. Zaychenko, V.V. Aleksandrov et al., Tightness of fixed connections hydraulic systems, Mechanical engineering, Moscow, (1977).

[2] A.S. Zubchenko, M.M. Koloskov, Yu.V. Kashirsky et al., in: A.S. Zubchenko (Eds.), Grade list of steels and alloys, Mechanical engineering, Moscow, (2003).

[3] Information on http://www.emco-world.com/uploads/tx_commerce/Milling_EMCOMILL_ E350-1200_EN_01.pdf.

[4] Information on https://www.renishaw.com/en/omp40-2-optical-transmission-probe--7992.

[5] Information on https://www.zeiss.co.in/metrology/products/systems/coordinate-measuring-machines/bridge-type-cmms/contura-g2.html.

[6] Information on https://www.sandvik.coromant.com/en-gb/products/pages/productdetails. aspx?c=r245-050q22-12h&Country=gb.

[7] H.R. Siller, C. Vila, C.A Rodriguez, J.V. Abellan-Nebot, Study of face milling of hardened AISI D3 steel with a special design of carbide tools, The International Journal of Advanced Manufacturing Technology. 40(1) (2009) 12-25.

DOI: 10.1007/s00170-007-1309-0

[8] C.Y. Wang, Y.X. Xie, Z. Qin, H.S. Lin, Y.H. Yuan, Q.M. Wang, Wear and breakage of TiAlN- and TiSiN-coated carbide tools during high-speed milling of hardened steel, Wear. 336-337 (2015) 29-42.

DOI: 10.1016/j.wear.2015.04.018

[9] J. Vetter, W. Burgmer, H. Dederichs, A. Perry, The architecture and performance of compositionally gradient and multi-layer PVD coating, Material Science Forum. 163-165 (1994) 527–532.

DOI: 10.4028/www.scientific.net/msf.163-165.527

[10] Information on https://www.sandvik.coromant.com/en-gb/products/pages/productdetails. aspx?c=R245-12%20T3%20M-PM% 201010.

[11] V.F. Makarov, Selection and appointment of optimal conditions for broaching workpieces from difficult-to-machine materials, Publishing house of Perm. state tech. University, Perm, (2008).

[12] A.A. Spiridonov, Planning an experiment in the study of technological processes, Mechanical engineering, Moscow, (1981).

[13] Stephen Moffat, Excel 2016 Introduction, The Mouse Training Company, London, (2016).

[14] S. Wolfram, An Elementary Introduction to the Wolfram Language, first ed., Wolfram Media, Inc., Champaign, IL, (2015).

[15] V.P. Borovikov, G.I. Ivchenko, Forecasting in the STATISTICA system in the WINDOWS environment. Fundamentals of theory and intensive practice on computer: training manual, Finance and statistics, Moscow, (2000).

[16] Brent Maxfield. Engineering with Mathcad: Using Mathcad to Create and Organize your Engineering Calculations, Butterworth-Heinemann, Oxford; Burlington, MA, (2006).

[17] A.V. Pepelyshev, Technological support of parameters of accuracy and roughness of flat surfaces of deep grooves by raster milling on CNC machines, Dissertation, Perm, (2016).

[18] O.V. Kulikova, Investigation of functions of several variables in the Mathcad system, UrGUPS, Yekaterinburg, (2007).
