A Note on the Change in the Surface Quality Characteristics during Flat Grinding of Titanium Intermetallic with Shape Memory Effect

Abstract:

Ti-based intermetallic compounds are characterized by low machinability, therefore, to obtain accurate dimensions and shape of the surface grinding and Wire EDM are used. The unique properties of NiTi intermetallic alloys are largely influenced by structural phase transformations and variations in microhardness caused by processing accompanied by thermal phenomena. Having an understanding of the physics of the process, it is possible to counteract negative effects, which helps to preserve thermomechanical properties of the final NiTi products. Accumulation of knowledge about the quality of processing with various abrasive tools is part of the larger research presented in this article. Samples of titanium nickelide with a temperature A_f=+25 ⁰С were abraded with ordinary and high porosity SiC wheels. The article studied phase transformations using X-ray diffraction analysis and microhardness. The experimental data were processed using mathematical statistics. X-ray diffraction patterns and microhardness analysis showed that a significant effect on the structural transformation and corresponding increase in microhardness is exerted by grinding with green SiC wheels with normal porosity caused by an increased thermal effect on the surface. Simultaneously, the impact of Wire EDM process on microhardness in preparing workpieces for grinding was evaluated. It was established that grinding of Ti-based intermetallic compounds with memory effect should be performed by SiC wheels with an open structure of high porosity.

• Periodical: Key Engineering Materials (Volume 910)
• Pages: 9-16
• DOI: https://doi.org/10.4028/p-1qo4d7
• Online since: February 2022
• Authors: Yakov Soler, Denis Kazimirov*
• Keywords: Grinding, Microhardness, NiTi, Phases, X-Ray

References

[1] S. Ezeddini, M. Boujelbene, E. Bayraktar, S.B. Salem, Optimization of the surface roughness parameters of Ti-Al intermetallic based composite machined by wire electrical discharge machining, Coatings 10 (2020) 900.

DOI: 10.3390/coatings10090900

[2] J.C. Williams, R.R. Boyer, Opportunities and issues in the application of titanium alloys for aerospace components, Metals 10 (2020) 705.

DOI: 10.3390/met10060705

[3] M. Schwartz, Encyсlopedia of smart materials, New York: John Wiley and Sons, (2002).

[4] A. Weirich, B. Kuhlenkötter, Applicability of shape memory alloys in aircraft interiors, Actuators 8 (2019) 61.

DOI: 10.3390/act8030061

[5] D.J. Hartl, D.C. Lagoudas, Aerospace applications of shape memory alloys, Proc. IMechE, Part G: J. Aerospace Eng. 221 (2007).

[6] G. Jodin, Y. Bmegaptche Tekap, J.M. Saucray, J.F. Rouchon, M. Triantafyllou, M. Braza, Optimized design of real-scale A320 morphing high-lift flap with shape memory alloys and innovative skin, Smart Mater. Struct. 27 (2018) 115005.

DOI: 10.1088/1361-665x/aae2ef

[7] J. Sun, Q. Guan, Y. Liu, J. Leng, Morphing aircraft based on smart materials and structures: a state-of-theart review, J. of Intelligent Material Systems and Structures 27 (2016) 17.

DOI: 10.1177/1045389x16629569

[8] B. Zhou, Z. Kang, Z. Wang, S. Xue, Finite element method on shape memory alloy structure and Its applications, Chin. J. Mech. Eng. 32:84 (2019).

DOI: 10.1186/s10033-019-0401-3

[9] Zh.M. Blednova, D.G. Budrevich, N.A. Makhutov, M.I. Chaevskij, Surface modification with shape memory materials for detachable joints obtaining, J. of Machinery Manufacture and Reliability 31 (2002) 5.

[10] R. Hood, D.K. Aspinwall, W. Voice, Creep feed grinding of a gamma titanium aluminide intermetallic alloy using SiC abrasives, J. of Materials Processing Technology 191 (2007) 1-3.

DOI: 10.1016/j.jmatprotec.2007.03.081

[11] R. Hood, D.K. Aspinwall, W. Voice, Creep feed grinding of gamma titanium aluminide and burn resistant titanium alloys using SiC abrasive, Int. J. of Machine Tools and Manuf. 47 (2007) 9.

DOI: 10.1016/j.ijmachtools.2006.10.008

[12] Y.I. Soler, D.Yu. Kazimirov, Influence of abrasive wheels characteristics on phases change of nitinol in different structural conditions, ARPN J. of Eng. and Applied Sci. 15 (2020) 11.

[13] A.P. Markopoulos, I.S. Pressas, D.E. Manolakos, A review on the machining of nickel-titanium shape memory alloys, Rev. Adv. Mater. Sci. 42 (2015) 28-35.

[14] E. Kaya, I. Kaya, A review on machining of NiTi shape memory alloys: the process and post process perspective, Int. J. Adv. Manuf. Technol. 100 (2019) 2045-2087.

DOI: 10.1007/s00170-018-2818-8

[15] M. Losertová, M. Štencek, D. Matýsek, O .Štefek, J. Drápala, Microstructure evolution of heat treated NiTi alloys, IOP Conf. Series: Mater. Sci. and Eng. 266 (2017) 012008.

DOI: 10.1088/1757-899x/266/1/012008

[16] T.S. Oliveira, L..S Procópio, P.H..A Martins, U.D. de Castro, M.A. Martins, C.B.S. Vimieiro, Characterization of mechanical properties of an alloy with shape memory – nitinol, COBEM 2015 23rd ABCM Int. Congr. of Mechanical Eng. (2015).

DOI: 10.20906/cps/cob-2015-0152

[17] L. Gua, G. Hea, W. Zhaoa, G. Lahoti, High performance hybrid machining of gamma-TiAl with blasting erosion arc machining and grinding, CIRP Annals – Manuf. Technology 69 (2020) 161-164.

DOI: 10.1016/j.cirp.2020.04.058

[18] X. Xia, T. Yub, W. Dinga, J. Xu, Grinding of Ti2AlNb intermetallics using silicon carbide and alumina abrasive wheels, Precision Eng. 53 (2018)134-145.

DOI: 10.1016/j.precisioneng.2018.03.007

[19] Z.I. Kremen', Yu.M. Zubarev, A.I. Lebedev, High-porous CBN vitrified wheels and their application in grinding high-ductile alloys, Metalloobrabotka 3 51 (2009) 2-4.
