Determination of Rational Structural Parameters for Sandwich Panels with a Cone-Shaped Filler’s Cells

Abstract:

The paper presents an algorithm, methodology and results of solving the primary problem of determining the stress-strain state and choosing design parameters for a three-layer structure under uniform pressure loading, depending on the size and pitch of support filler’s cells, as well as geometry features of the simulated structure.

• Periodical: Key Engineering Materials (Volume 910)
• Pages: 826-833
• DOI: https://doi.org/10.4028/p-3amo61
• Online since: February 2022
• Authors: Anatoly A. Zotov, Anton N. Volkov, Andrey M. Kokurov*
• Keywords: Cell, Cone-Shaped Filler, Finite Element Method, Optimal Size, Three-Layer Panel
