Experimental Response of Rubble Stone Masonry Walls Retrofitted with Basalt Textile Reinforced Mortar under Compressive-and-Shear Load

Abstract:

Seismic events recently occurred in Europe highlighted the vulnerability of unreinforced masonry structures, representing the majority of the built heritage, to earthquake-induced loads. In particular, the in-plane capacity of shear walls under seismic loadings appeared sensibly modest, both in terms of strength and ultimate displacement, and their failure mode sudden and brittle. Textile Reinforced Mortar (TRM) composites proved to be a proper strengthening solution for the seismic upgrade of such walls. With the aim of gaining a deeper knowledge on the behavior of historical walls retrofitted with TRM and subjected to compression-and-shear, this paper summarizes the results of an experimental campaign characterized by quasi-static cyclic shear-compression tests. The specimens under study reproduced the rubble stone masonry typical of vernacular structures of the UNESCO historical district of Lyon (France). Specifically, the work concerns a full scale masonry wall tested under loading until the development of diagonal cracks and than repaired by a composite constituted by a basalt textile embedded in a lime mortar matrix applied onto the external surfaces as a plaster. The use of a lime mortar plaster to reinforce the structural element permits the development of a solution compatible with the historical substrate. Experimental outcomes revealed how Basalt TRMs succeeded in improving the response of damaged vernacular wall, both in terms of strength and displacement capacity.

• Periodical: Key Engineering Materials (Volume 916)
• Pages: 483-490
• DOI: https://doi.org/10.4028/p-svlf1t
• Online since: April 2022
• Authors: Carmelo Caggegi*, Aron Gabor, Pietro Meriggi, Gianmarco de Felice
• Keywords: Basalt, Calcarenite Limestone, In-Plane Capacity, Lime Mortar, Masonry, Rehabilitation, Textile Reinforced Mortar (TRM)

References

[1] M. Godio, F. Vanin, S. Zhang, K. Beyer, Quasi-static shear-compression tests on stone masonry walls with plaster: Influence of load history and axial load ratio. Eng Struct 192 (2019) 264-278.

DOI: 10.1016/j.engstruct.2019.04.041

[2] M. Del Zoppo, M. Di Ludovico, A. Prota, Analysis of FRCM and CRM parameters for the in-plane shear strengthening of different URM types. Compos B Eng 171 (2019) 20-33.

DOI: 10.1016/j.compositesb.2019.04.020

[3] American Concrete Institute. ACI 549.6R-20: Guide to Design and Construction of Externally Bonded Fabric-Reinforced Cementitious Matrix (FRCM) and Steel-Reinforced Grout (SRG) Systems for Repair and Strengthening Masonry Structures. Farmington Hills, MI, USA, (2020).

DOI: 10.14359/51702356

[4] National Research Council. CNR-DT 215/2018: Guide for the design and construction of Externally Bonded Fibre Reinforced Inorganic Matrix systems for strengthening existing structures. Rome 06/02/(2019).

[5] P. Meriggi, G. de Felice, S. De Santis, S. Fares, Design of the shear strengthening of masonry walls with fabric reinforced cementitious matrix. Constr. and Build. Mater. 279 (2021) 122452.

DOI: 10.1016/j.conbuildmat.2021.122452

[6] G. Ferrara, C. Caggegi, E. Martinelli, A. Gabor, Shear capacity of masonry walls externally strengthened using Flax-TRM composite systems: experimental tests and comparative assessment, Constr. Build. Mater. 261 (2020) 12049.

DOI: 10.1016/j.conbuildmat.2020.120490

[7] C.G. Papanicolau, T.C. Triantafillou, K. Karlod, M. Papathanasiou, Textile-reinforced mortar (TRM) versus FRP as strengthening material of URM walls: in-plane cyclic loading. Mat. Struct. 40 (2007) 1081-1097.

DOI: 10.1617/s11527-006-9207-8

[8] N. Gattesco, C. Amadio, C. Bedon, Experimental and numerical study on the shear behavior of stone masonry walls strengthened with GFRP reinforced mortar coating and steel-cord reinforced repointing. Eng. Struct. 90 (2015) 143-157.

DOI: 10.1016/j.engstruct.2015.02.024

[9] N. Reboul, Z. Mesticou, A. Si Larbi, E. Ferrier, Experimental study of the in-plane cyclic behaviour of masonry walls strengthened by composite materials. Constr. Build. Mater., 164 (2018) 70-83.

DOI: 10.1016/j.conbuildmat.2017.12.215

[10] Information on https://whc.unesco.org/fr/list/872/.

[11] P.Meriggi, C. Caggegi, A. Gabor, G. De Felice, Shear-compression tests on stone masonry walls strengthened with basalt Textile Reinforced Mortar (TRM), manuscript under review.

DOI: 10.1016/j.conbuildmat.2021.125804
