Innovative Method of Embedding Optical Fiber inside Titanium Alloy Utilizing Friction Stir Forming

Abstract:

The development of FBG (Fiber Bragg Grating) sensors is essential for intelligent parts of airplanes to achieve ultra-lightweight structures and intelligent aviation control. Awaiting solution is embedding technology of optical fiber sensors into the base material of the parts; however, it has been challenging to embed fibers into high melting temperature point alloys like titanium-based materials without having any defects. Present research fulfills the mentioned demands effectively by utilizing Friction Stir Forming (FSF). Precisely, optical fiber has been placed into a guide slit inside the titanium sheet. Then, FSF was applied to the surface of the titanium. As a result, titanium plasticizes and flows into the guide slit. This mechanically interlocks the optical fiber inside the titanium alloy. This solid-state stirring process can bury sensors inside the titanium to protect the sensor from harsh environments. Embedded sensors will detect the strain and temperature of the host titanium in real-time. Moreover, this research can have further considerable effects on the areas like aerospace and artificial intelligence systems that demand real-time condition monitoring systems.

• Periodical: Key Engineering Materials (Volume 934)
• Pages: 67-73
• DOI: https://doi.org/10.4028/p-683ks0
• Online since: November 2022
• Authors: Hamed Mofidi Tabatabaei*, Takahiro Ohashi, Tadashi Nishihara
• Keywords: Friction Stir Forming, Friction Stir Welding, Functional Materials, Mechanical Joining, Optical Fiber Sensor, Titanium

References

[1] The Ohio State University, Rajendra Singh, 614.292.9044.

[2] A. Ogawa, M. Niikura, C. Ouchi, K. Minikawa, and M. Yamada, Development and Applications of Titanium Alloy SP-700 with High Formability,, Journal of Testing and Evaluation 24, no. 2 (1996): 100-109.

[3] X. Li, Embedded Sensors in Layered Manufacturing,, Ph.D., Mechanical Engineering, Stanford University, (2001).

[4] Y. Li, W. Liu, Y. Feng, and H. Zhang, Ultrasonic embedding of nickel-coated fiber Bragg grating in aluminum and associated sensing characteristics,, Opt. Fiber Technol., vol. 18, no. 1, p.7–13, (2012).

DOI: 10.1016/j.yofte.2011.09.004

[5] S. Sandlin, T. Kosonen, A. Hokkanen, L. Heikinheimo, Use of brazing technique for manufacturing of high-temperature fiber optical temperature and displacement transducer, Materials Science and Technology, Vol. 23, Iss. 10, (2007).

DOI: 10.1179/174328407x226662

[6] W.M. Thomas et al. Friction Stir Welding,, International Patent Application No. PCT/GB92/02203.

[7] T. Nishihara, Development of Friction Stir Forming,, Mater. Sci. Forum, 426-432 (2003) 2971-2978.

DOI: 10.4028/www.scientific.net/msf.426-432.2971

[8] H. M. Tabatabaei et al., Friction Stir Forming for Mechanical Interlocking of Ultra-Thin Stainless Steel Strands and Aluminum Alloys,, Defect and Diffusion Forum, 382, pp.114-119, (2018).

DOI: 10.4028/www.scientific.net/ddf.382.114

[9] Hamed Mofidi Tabatabaei, Takahiro Ohashi, Tadashi Nishihara, Effect of Friction Stir Forming Parameters and Heat Treatment on Mechanical Properties of Fibre-Reinforced Aluminium Alloy, Key Engineering Materials, 918: 57-66, April (2022).

DOI: 10.4028/p-l892cv

[10] Hamed Mofidi Tabatabaei, Keita Kobayashi, Takahiro Ohashi, Tadashi Nishihara, Effect of Friction Stir Forming Process Parameters on Mechanical Interlock between A5083Alloy and Ultra-Thin Stainless Steel Strands, Key Engineering Materials 858:27-32, August (2020).

DOI: 10.4028/www.scientific.net/kem.858.27

[11] Hamed Mofidi Tabatabaei, Tadashi Nishihara, Friction Stir Forming for Mechanical Interlocking of Ultra-Thin Stainless Steel Strands and Aluminum Alloys, Defect and Diffusion Forum 382:114-119 January (2018).

DOI: 10.4028/www.scientific.net/ddf.382.114

[12] Hamed Mofidi Tabatabaei, Tadashi Nishihara, Effect of Friction Stir Welding on Mechanical properties of Zn-22Al Superplastic Alloy, International Journal of Engineering Research in Mechanical and Civil Engineering, 2(12) 63-68, December (2017).

DOI: 10.1007/s40194-016-0406-9

[13] Hamed Mofidi Tabatabaei, Tadashi Nishihara, Friction stir forming for mechanical interlocking of insulated copper wire and Zn-22Al superplastic alloy, Weld World, 61:47–55, December (2016).

DOI: 10.1007/s40194-016-0406-9

[14] Hamed Mofidi Tabatabaei, Takahiro Hara, Tadashi Nishihara, Production of a Superplastic Vibration-Damping Steel Sheet Composite Using Friction Stir Forming, Materials Science Forum 838-839:574-580, January (2016).

DOI: 10.4028/www.scientific.net/msf.838-839.574

[15] Takahiro Ohashi, Tadashi Nishihara, Hamed Mofidi Tabatabaei, Mechanical Joining Utilizing Friction Stir Forming, Materials Science Forum, 1016:1058-1064, January (2021).

DOI: 10.4028/www.scientific.net/msf.1016.1058

[16] Takahiro Ohashi, Hamed Mofidi Tabatabaei, Tadashi Nishihara, Cylindrical extrusions on A5083 aluminum alloy plate fabricated by friction stir forming, AIP Conference Proceedings, 1896 (1): 080002, October (2017).

DOI: 10.1063/1.5008082
