Aspects of the Influence of the Taper Profile of the Welding Tool pin on the Dimensions of FSW and SFSW Welded Joints in EN AW 1200 Aluminum Alloy

Abstract:

The joining of metallic materials by using the friction stir welding process is carried out with rotating welding tools having different geometries. The paper presents aspects that show the influence of the conical profile of the welding tool pin on the dimensions of friction stir welded joints FSW in air and SFSW in liquid environment for EN AW 1200 aluminum alloy. The tools analyzed in the experimental research have had smooth conical pin and conical pin with four flat chamfers respectively, macrostructural investigations being carried out to a comparatively analyze of the welded joint dimensions. The results are useful for experimental research on FSP processing in air and SFSP in liquid environment of aluminum alloys that will be carried out within the Nucleu PN 23 37 01 02 project underway at ISIM Timisoara.

• Periodical: Key Engineering Materials (Volume 994)
• Pages: 99-107
• DOI: https://doi.org/10.4028/p-ZeO4A4
• Online since: November 2024
• Authors: Emilia Dobrin*, Lia-Nicoleta Botila, Gabriela-Victoria Mnerie, Ion Aurel Perianu, Emilia-Florina Binchiciu, Radu Nicolae Popescu
• Keywords: EN AW 1200 Aluminum Alloy, Friction Stir Welding, Submerged Friction Stir Welding, Taper Profile, Tool Geometry

References

[1] Mohamed H. El-Moayed, Ahmed Y. Shash, Engineering Reports.2021;3:e12270, wileyonlinelibrary.com/journal

[2] Devang Sejani, Wenya Li, Vivek Patel, Critical Reviews in Solid State and Materials Sciences, Volume 47, 2022 - Issue 6

[3] Journal of Materials Research and Technology, Vol. 20, 2022, Pg. 397-414

[4] S.J. Vijay, N. Murugan, Materials and Design 31 (2010) 3585–3589

[5] Information on https://www.fsw-tech.eu

[6] S.Verma, M. Gupta and Joy P. Misra, Proc IMechE Part B: J Engineering Manufacture, pg.1-13

[7] Miguel A., R. Pereira, I. Galvão, J. D. Costa, Appl. Sci. 2022, 12, 2744. https://doi.org/10.3390/ app12052744

[8] Influence of additional heating in friction stir welding of dissimilar aluminum alloys with different tool pin profiles November 2019, The International Journal of Advanced Manufacturing Technology 105(1-4) Follow journal

DOI: 10.1007/s00170-019-04186-z

[9] K. Ramanjaneyulu, G. Madhusudhan Reddy, Journal of Materials Engineering and Performance volume 22, pages 2224–2240 (2013)

[10] C. Rathinasuriyan, E. Pavithra, International Journal of Precision Engineering and Manufacturing-Green Technology volume 8, pages687–701 (2021)

[11] Yue Mao, Run Wu, 2023, The International Journal of Advanced Manufacturing Technology 128(7-8): 1-12

[12] J.R. Davis, Alloying: Understanding the Basics, Aluminum and Aluminum Alloys-book, pg. 351-416

DOI: 10.31399/asm.tb.aub.t61170351

[13] Information on https://alualloy.cn/properties-and-chemical-composition-of-1200-aluminum-alloy

[14] Shittu, M. D. Olaniyi, A. E, Effect of magnesium on some mechanical properties of 1200 Aluminium Alloy, Ife Journal of Science vol. 23, no. 2 (2021), pg. 147-152

DOI: 10.4314/ijs.v23i2.15

[15] Information on https://steelmax.co.kr

[16] Information on https://www.ijser.org/paper/Tungsten-Carbide-Composite-A-Review.html

[17] Information on https://en.wikipedia.org/wiki/Tungsten_carbide#cite_note-Blau2003-4.
