Performance Comparison of the Hexagon and the Overexpanded Honeycomb

Abstract:

With the development of radar-detecting technology, stealth technology is important for military weapons and equipment. As a typical structural stealth material, wave absorption honeycomb has a wide range of application prospects and research value. The light and high absorption wave absorption honeycomb that uses electromagnetic-modified aramid paper as a raw material has the advantages of light density and good absorption performance, making it suitable for the lightweight requirements of the new equipment. Here, the electromagnetic-modified aramid was the raw material of the honeycomb. The hexagon honeycomb and overexpanded honeycomb were prepared. We also analyzed the influence of the cell shapes on the honeycomb properties. The results showed that cell shapes had little effect on the plane compression and shear performance of L. The overexpanded honeycomb’s L and W shear performance was basically the same. The hexagon and overexpanded honeycomb have good electromagnetic wave absorption performance in 1 GHz ~ 18 GHz frequency band.

• Periodical: Key Engineering Materials (Volume 999)
• Pages: 49-53
• DOI: https://doi.org/10.4028/p-3T3FJp
• Online since: December 2024
• Authors: Zhen Jia*, Yan Ming Liu, Tao Su, Xiao Wu
• Keywords: Comparison, Hexagon Honeycomb, Overexpanded Honeycomb, Performance

References

[1] W. H. Choi, C. G. Kim. Broadband microwave-absorbing honeycomb structure with novel design concept. Compos. Part B. 83 (2015) 14-20.

DOI: 10.1016/j.compositesb.2015.08.027

[2] Y. Guo, Z. Sun, F. Meng. Radar Wave Absorbing Performance Test of Honeycomb Sandwich Structure. Aeronaut Manuf. Tech. 3 (1997) 8-10.

[3] J. Ma, M. Zhao, K. Zhang, S. Mu. A Preliminary Discussion on Aircrafts' Stealth Techniques and Radars' Countermeasures. National Def. Sci. Tech. 30(2009) 38-44.

[4] H. Luo, F. Chen, F. Wang, X. Wang, W. Dai, S. Hu, R. Gong. Preparation and microwave absorption properties of honeycomb core structures coated with composite absorber. AIP Adv. 8 (2018) 056635-1-7.

DOI: 10.1063/1.5005163

[5] K. Ma, G. Zhang, L. Liu, Z. Yan. Research progress of Technology for Sandwich Structural Absorbing Stealthy Composite Materials. Dev. Appl. Mat. 25 (2010) 53-57.

[6] X. Jin, Z. Wang, J. Ning, G. Xiao, E. Liu, X. Shu. Dynamic response of sandwich structures with graded auxetic honeycomb cores under blast loading. Compos. Part B. 106 (2016) 206-217.

DOI: 10.1016/j.compositesb.2016.09.037

[7] S. Xie, Z. Ji, Y. Yang, G. Hou, J. Wang. Electromagnetic wave absorption properties of honeycomb structured plaster boards in S and C bands. J. Build. Eng. 7 (2016) 217-223.

DOI: 10.1016/j.jobe.2016.06.008

[8] P. Wang, Y. Zhang, H. Chen, Y. Zhou, F. Jin, H. Fan. Broadband radar absorption and mechanical behaviors of bendable overexpanded honeycomb panels. Compos. Sci. Technol. 162 (2018) 33-48.

DOI: 10.1016/j.compscitech.2018.04.015

[9] S. Huang, Y. Liu, K. Wen, X. Su, C. Liang, H. Duan, G. Zhao. Optimization design of a novel microwave absorbing honeycomb sandwich structure filled with magnetic shear-stiffening gel. Compos. Sci. Technol. 232 (2023) 1-10.

DOI: 10.1016/j.compscitech.2022.109883

[10] H. Yan, X. Yao, B. Fu, S. Xuan, T. Qin. Electromagnetic response of grading honeycomb composites for broadband microwave absorption. Compo. Structure. 321(2023) 1-9.

DOI: 10.1016/j.compstruct.2023.117280

[11] Y. Zhao, Y. Shan, G. Ji, Y. Sun, W. Shi, M. Li. Enhanced Microwave-Absorbing Property of Honeycomb Sandwich Structure with a Significant Interface Effect. Mater (Basel). 15(2022) 5741.

DOI: 10.3390/ma15165741
