Analysis of Thermal Effects within Cylindrical Shape Solid-State Laser Rod

Abstract:

In this work, a temperature-dependent analytical model was modified to predict the thermal effects of diode laser double–end-pumped cylindrical laser rod under Gaussian pump beam distribution. Heat load and temperature distribution were analyzed using the Kirchhoff integral transform method. Results show that a maximum temperature difference of approximately 69.61 K was obtained on each side face of the laser rod at a maximum power of 40 W (equally divided on each face). The total thermal focal length of approximately 34.64 mm was calculated under the Gaussian pumping profile. The finite element method code incorporated with well-verified software was used to numerically verify the obtained results, where the analytical and numerical results are highly matched. The results reveal that the total thermal focal length produced in a double–end-pumped geometry is two times less than that obtained from a single-end-pumped geometry.

• Periodical: Materials Science Forum (Volume 1002)
• Pages: 264-272
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1002.264
• Online since: July 2020
• Authors: Mohammed Jalal Abdul Razzaq*, Kadhim A. Hubeatir
• Keywords: Heat Conduction, Laser Materials, Lasers, Numerical Simulation

References

[1] K.S. Shibib, Mohammed A. Munshid, M.J. AbdulRazzaq, L.H. Salman, Transient Analytical Solution of Temperature Distribution and Fracture Limits in Pulsed Solid State Laser Rod, Therm. Sci. 21 (2017) 1–15.

DOI: 10.2298/tsci141011090s

[2] B.A. Usievich, V.A. Sychugov, F. Pigeon, A. Tishchenko, Analytical treatment of the thermal problem in axially pumped solid-state lasers, IEEE J. Quantum Electron. 37 (2001).

DOI: 10.1109/3.945327

[3] Y. Shen, Y. Bo, N. Zong, Y.D. Guo, Q.J. Peng, J. Li, Y.B. Pan, J.Y. Zhang, D.F. Cui, Z.Y. Xu, Experimental and Theoretical Investigation of Pump Laser Induced Thermal Damage for Polycrystalline Ceramic and Crystal Nd:YAG, IEEE J. Sel. Top. Quantum Electron. 21 (2015).

DOI: 10.1109/jstqe.2014.2351791

[4] W. Xie, Y. Kwon, W. Hu, F. Zhou, Thermal modeling of solid state lasers with super-Gaussian pumping profiles, Opt. Eng. 42 (2003) 1787.

DOI: 10.1117/1.1572499

[5] P. Shi, W. Chen, L. Li, A. Gan, Semianalytical thermal analysis of thermal focal length on Nd:YAG rods., Appl. Opt. 46 (2007) 6655–6661.

DOI: 10.1364/ao.46.006655

[6] F. Kalantarifard, H. Nadgaran, P. Elahi, The analytical and numerical investigation of thermo- optic effects in double-end-pumped solid state lasers, Int. J. Phys. Sci. 4 (2009) 385–389.

[7] M.J. AbdulRazzaq, A.Z. Mohammed, A.K. Abass, K.S. Shibib, A new approach to evaluate temperature distribution and stress fracture within solid state lasers, Opt. Quantum Electron. 51 (2019) 294.

DOI: 10.1007/s11082-019-2012-8

[8] J. Liu, X. Chen, Y. Yu, C. Wu, F. Bai, G. Jin, Analytical solution of the thermal effects in a high-power slab Tm:YLF laser with dual-end pumping, Phys. Rev. A. 93 (2016) 1–7.

DOI: 10.1103/physreva.93.013854

[9] M. Sayem El-Daher, Finite element analysis of thermal effects in diode end-pumped solid-state lasers, Adv. Opt. Technol. 2017 (2017) 1–15.

DOI: 10.1155/2017/9256053

[10] R.M. El-Agmy, N. Al-Hosiny, Thermal analysis and experimental study of end-pumped Nd: YLF laser at 1053 nm, Photonic Sensors. 7 (2017) 329–335.

DOI: 10.1007/s13320-017-0412-6

[11] H.M. Ahmed, M.J. AbdulRazzaq, A.K. Abass, Numerical Thermal Model of Diode Double-End-Pumped Solid State Lasers, Int. J. Nanoelectron. Mater. 11 (2018) 473–480.

[12] L. Cini, J.I. Mackenzie, Analytical thermal model for end-pumped solid-state lasers, Appl. Phys. B Lasers Opt. 123 (2017).

DOI: 10.1007/s00340-017-6848-y

[13] M.H.M. Dindarlu, A. Maleki, H. Saghafifar, M.K. Tehrani, S. Baghali, Analytical model for temperature, stress and strain distribution inside a side-pumped Nd:YAG laser rod having a Gaussian pump profile, Laser Phys. 25 (2015) 1–8.

DOI: 10.1088/1054-660x/25/4/045001

[14] S. Bjurshagen, R. Koch, Modeling of energy-transfer upconversion and thermal effects in end-pumped quasi-three-level lasers, Appl. Opt. 43 (2004) 4753.

DOI: 10.1364/ao.43.004753

[15] A.K. Cousins, Temperature and thermal stress scaling in finite-length end-pumped laser rods, IEEE J. Quantum Electron. 28 (1992) 1057–1069.

DOI: 10.1109/3.135228

[16] C. Pfistner, R. Weber, Thermal beam distortions in end-pumped Nd: YAG, Nd: GSGG, and Nd: YLF rods, IEEE J. Quantum Electron. 30 (1994) 1605–1615.

DOI: 10.1109/3.299492
