Photonic Crystal Fiber Sensor for Blood with Different Concentration of Zinc

Abstract:

Zinc is one of the important material in human blood because of its effect in defensive system work for properly and it plays an important role in growth, wound healing Medically zinc concentration effect directly in skin health so it's important to make a sensor for discover zinc and its concentration change in human blood for each of male and female. Optical fibers are used as a sensor for detecting zinc and its concentration by transmitted laser signal through the optical fiber by using different types (single mode fiber SMF, photonic crystal fiber PCF) by studying the results of output laser the detection can be seen for zinc concentration change, the design of small PCF which the same LMA_10 but smaller in its radius of core and cladding even the distance between cores. The smallest PCF size has the best detection for all zinc concentration change in blood all that was done by comsol Multiphysics 5.4 simulation program

• Periodical: Materials Science Forum (Volume 1002)
• Pages: 290-299
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1002.290
• Online since: July 2020
• Authors: Raghad Hani*, Bushra R. Mahdi, Ayad Z. Mohammad
• Keywords: Blood, Comsol Multiphysics, Concentration, Design, Photonic Crystal Fiber, Zinc

References

[1] A.Shai, H.I. Maibach,Wound Healing and Ulcers of the Skin, Germany, 2005, chapter 18.

[2] L.Prashanth, K.Kattapagari ,R. Chitturi,V. Baddam,L. Prasad. A review on role of essential trace elements in health and disease. J. NTR Univ Health Sci (2015)75-85.

DOI: 10.4103/2277-8632.158577

[3] A.Z. Mohammed" photonic crystal fiber mach zehnder interferometer pHsensing" AIP conference proceedings .(2018) 1-10.

DOI: 10.1063/1.5080823

[4] F.Poil, A.Cucinotta, S.Selleri" photonic crystal fiber properties and application.Springer (2007).

[5] D. E. Johnson D.E. Comman, Southwest Research Institute , Health Implications of Sewage Treatment Facilities, (1978).

[6] Shih-Kang Fan, Da-Jeng Yao, Yi-Chung Tung Optofluidics 2015 ,published in Micromachines,(2018).

[7] J. Villatoro, V. Finazzi, G. Badenes and V. Pruneri, Highly Sensitive Sensors Based on Photonic Crystal Fiber Modal Interferometers, Journal of Sensors, Spain, , (2009)1-11.

DOI: 10.1155/2009/747803

[8] N.A. Salman and H.J. Taher Refractive index sensor based on a solid-core photonic crystal fiber interferometer,, January (2017 )99-105. Bottom of Form5.reference data for engineers radio, electro55.

DOI: 10.30723/ijp.v15i34.125

[9] A. H. Abdulhadi, S.-j. Qiu, and A. H. Al-Janabi, DMSO-based photonic crystal f iber sensor with enhanced sensitivity,, Chinese Optics Letters, (2014)1-10.

DOI: 10.3788/col201412.020603

[10] B. R. Mahdi, A Z. Mohammed and F. F. Ridha, Micro-structure Chemical Fiber Sensor,,Atti della Fondazione Giorgio Ronchi Anno journal LXXII, (2016) 250-255.

[11] A. H. Abdulhadi, A.Z. Mohammed, N.H. Numan, R.Hani THz waves propagation through photonic crystal fiber, International Journal of Innovative Science, Engineering & Technology, (2015)40-45.

[12] K.A. Fidanboylu, and H. S. Efendioglu, Fiber optic sensors and their applications", 5th International Advanced Technologies Symposium (IATS,09), ( 2009)12-20.

[13] A. Z.Mohammed, B. R.Mahdi, L.K. Humdi" Photonic crystal fiber magnetic field sensor based on Ampere Force" Sci.Int.(Lahore), (2017) 99-102.
