Prediction Model and Influence of Fe₂O₃ on the Mechanical Properties of Porcelain with POFA as Quartz Replacement

Abstract:

Palm oil fuel ash (POFA) is solid waste from palm oil industries discarded after burning of shell, fiber, kernel and empty fruit bunches to heat boiler and generate electricity. A standard porcelain consisting of clay, feldspar and quartz is produced by sintering at temperature between 1300 °C to 1400 °C for toughness and translucency. This research developed a prediction model for optimum physical and mechanical properties of porcelain by addition of Fe₂O₃ at 5 wt.%. Quartz was replaced with POFA powder at 15 wt.% and Fe₂O₃ was also added at 5 wt.% of POFA mixed with others porcelain composition. Then the powder was dry pressed into pellet at 91 MPa and the samples were sintered at 1150 °C. The bulk density, compressive strength and Vickers microhardness were found to increase by addition of Fe₂O₃ at 5 wt.%. Prediction model was developed and from the predicted values it is revealed that, the model is efficient and good for the purpose of this research.

• Periodical: Materials Science Forum (Volume 1010)
• Pages: 244-249
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1010.244
• Online since: September 2020
• Authors: Sani Garba Durumin-Iya, Mohamad Zaky Noh*, Norazreen Sharip, Siti Noraiza Ab Razak, Mohd Warikh Abdul Rashid, Julie Juliewatty Mohamed, Mohd Al Amin Muhamad Nor
• Keywords: Fe₂O₃, Palm Oil Fuel Ash (POFA), Polynomial Analysis, Porcelain, Regression

References

[1] K. Muthusamy, N. Zamri, M. Amirulkhairi, Effect of mixing ingredient on compressive strength of oil palm shell lightweight aggregate concrete containing palm oil fuel ash, Procedia Eng., 125 (2015) 804–810.

DOI: 10.1016/j.proeng.2015.11.142

[2] A.S.M.A. Awal, I. A. Shehu, Performance evaluation of concrete containing high volume palm oil fuel ash exposed to elevated temperature, Constr. Build. Mater., 76 (2015) 214–220.

DOI: 10.1016/j.conbuildmat.2014.12.001

[3] V. Sata, C. Jaturapitakkul, K. Kiattikomol, Utilization of palm oil fuel ash in high-strength concrete, J. Mater. Civ. Eng., 16 no. 6 (2004) 623–628.

DOI: 10.1061/(asce)0899-1561(2004)16:6(623)

[4] S.D.I. Garba, M.Z. Noh, A.R. Siti Noraiza, N. Sharip, N.A.A. Kutty, Effect of Iron (111) Oxide (Fe2O3) as an Additive and substitution of quartz with POFA on physico-mechanical properties of porcelain, Int. J. Nanoelectron. Mater., 12 no. 2 (2019) 175-184.

[5] L. Esposito, A. Tucci, D. Naldi, The reliability of polished porcelain stoneware tiles, J. Eur. Ceram. Soc., 25 no. 2005 (2004) 1487–1498.

DOI: 10.1016/j.jeurceramsoc.2004.05.030

[6] A. Araújo, Polynomial regression with reduced over-fitting - The PALS technique, Measurement, 124 no. 2018 (2018) 515–521.

DOI: 10.1016/j.measurement.2018.04.045

[7] A. Deshmukh, S.D. Gore, Regression: an efficient data analysis technique, Int. J. Innov. Res. Comput. Commun. Eng., 5 no. 3 (2017) 5901–5903.

[8] T.K. Mukhopadhyay, S. Ghosh, J. Ghosh, S. Ghatak, H.S. Maiti, Effect of fly ash on the physico-chemical and mechanical properties of a porcelain composition, Ceram. Int., 36 no. 3 (2010) 1055–1062.

DOI: 10.1016/j.ceramint.2009.12.012

[9] Ç. Koca, N. Karakus, N. Toplan, H.Ö. Toplan, Use of borosilicate glass waste as a fluxing agent in porcelain bodies, Ceram. Process. Res., 13 no. 6 (2012) 693–698.

[10] C.P. Bergmann, Traditional and glass powder porcelain: technical and microstructure analysis, J. Eur. Ceram. Soc., 24 (2004) 2383–2388.

DOI: 10.1016/j.jeurceramsoc.2003.08.003

[11] D. H. Piva, R. H. Piva, J. Venturini, J. Ramon, Effect of Fe2O3 content on the electrical resistivity of aluminous porcelain applied to electrical insulators, Ceram. Int., 42 no. 4, (2016) 5045–5052.

DOI: 10.1016/j.ceramint.2015.12.016

[12] Z. Dilshad, I. Sktani, M.M. Ratnam, and Z.A. Ahmad, Influence of combined CaO and CaCO3 additions on the microstructure and properties of ZTA, J. Aust. Ceram. Soc., 52 no. 1 (2016) 167–176.
