Anisotropy of Plastic Deformation in Hexagonal Metals

Abstract:

Geometric aspects of the shear processes in hexagonal metals are analysed. They can be divided into three groups: those localized essentially between neighbouring atomic planes, occurring in narrow slabs along particular atomic planes, or covering a large crystal volume. Obviously, dislocation glide and deformation twinning are principal types of such processes. On the geometrical level, the dislocation slip as well as twin propagation are controlled by Schmid factors. Since the sample loaded by external stress can sometimes give way to fracture (cleavage) under tensile stress, it has to be also mentioned. The main aim of this work is to show only on geometrical grounds for which sample orientation which process is more likely to occur. More complex shear processes that take place during double twinning are also briefly considered. In polycrystals, the shear phenomena lead to texture formation when the processes that control the behaviour of materials may be those that act in a similar way in single crystals.

• Periodical: Materials Science Forum (Volume 1016)
• Pages: 1091-1096
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1016.1091
• Online since: January 2021
• Authors: Vaclav Paidar*, Jaroslav Čapek
• Keywords: Dislocation, Fracture, Hexagonal Metals (Mg, Ti, Zn), Twins

References

[1] J. Hirsch, T. Al-Samman, Superior light metals by texture engineering: Optimized aluminum and magnesium alloys for automotive applications, Acta Mater. 61 (2013), 818-843.

DOI: 10.1016/j.actamat.2012.10.044

[2] M. Arul Kumar, I.J. Beyerlein, C.N. Tome, A measure of plastic anisotropy for hexagonal close packed metals: Application to alloying effects on the formability of Mg, J. Alloys Compd. 695 (2017), 1488-1497.

DOI: 10.1016/j.jallcom.2016.10.287

[3] C.N. Elias, J.H.C. Lima, R. Valiev, M.A. Meyers, Biomedical Applications of Titanium and its Alloys, JOM March (2008), 46-49.

DOI: 10.1007/s11837-008-0031-1

[4] C. Veiga, J.P. Davim, A.J.R. Loureiro, Properties and applications of titanium alloys: A brief review, Rev. Adv. Mater. Sci. 32 (2012), 14-34.

[5] M. Yoo, Slip, twinning, and fracture in hexagonal close-packed metals, Metall. Mater. Trans. A 12 (1981), 409-418.

DOI: 10.1007/bf02648537

[6] N.H. Macmillan and A. Kelly, On the relationship between ideal tensile strength and surface energy, Mater. Sci. Eng. A 10 (1972), 139-143.

DOI: 10.1016/0025-5416(72)90078-x

[7] E. Clouet, D. Caillard, N. Chaari, F. Onimus and D. Rodney, Dislocation locking versus easy glide in titanium and zirconium, Nat. Mater. 14 (2015), 931-936.

DOI: 10.1038/nmat4340

[8] H.S. Rosenbaum, Non-basal slip and twinning accommodation in zinc crystals, Acta Metall. 9 (1961), 742-748.

DOI: 10.1016/0001-6160(61)90104-3

[9] M.Z. Bian, K.S. Shin, {10-1 2} twinning behavior in magnesium single crystal, Met. Mater. Int. 19 (2013), 999-1004.

DOI: 10.1007/s12540-013-5012-4

[10] K.Y. Xie, Z. Alam, A. Caffee and K.J. Hemker, Pyramidal I slip in c-axis compressed Mg single crystals, Scripta Mater. 112 (2016), 75-78.

DOI: 10.1016/j.scriptamat.2015.09.016

[11] S.R. Agnew, L. Capolungo and C.A. Calhoun, Connections between the basal I1 growth, fault and c+a dislocations, Acta Mater. 82 (2015), 255-265.

DOI: 10.1016/j.actamat.2014.07.056

[12] B. Yin, Z. Wu, W.A. Curtin, Comprehensive first-principles study of stable stacking faults in hcp metals, Acta Mater. 123 (2017), 223-234.

DOI: 10.1016/j.actamat.2016.10.042

[13] V. Vitek and V. Paidar, Non-planar dislocation cores: A ubiquitous phenomenon affecting mechanical properties of crystalline materials, in Vol. 14 of Dislocations in Solids, Editor J.P. Hirth, Amsterdam: North-Holland, 2008, 439-514.

DOI: 10.1016/s1572-4859(07)00007-1

[14] M.H. Yoo, J.R. Morris, K.M. Ho, S.R. Agnew, Nonbasal deformation modes of HCP metals and alloys: Role of dislocation source and mobility, Metall. Mater. Trans. A 33 (2002), 813-822.

DOI: 10.1007/s11661-002-0150-1

[15] X.-L. Nan, H.-Y. Wang, L. Zhang, J.-B. Li, Q.-Ch. Jiang, Calculation of Schmid factors in magnesium: Analysis of deformation behaviors, Scripta Mater. 67 (2012), 443-446.

DOI: 10.1016/j.scriptamat.2012.05.042

[16] J.W. Christian and S. Mahajan, Deformation twinning, Prog. Mater. Sci. 39 (1995), 1-157.

[17] V. Paidar, Displacive processes in systems with bcc parent lattice, Prog. Mater. Sci. 56 (2011), 841-851.

DOI: 10.1016/j.pmatsci.2011.01.009

[18] L.P. Kubin, A. Fourdeux, J.Y. Guedou, J. Rieu, Pseudoelasticity and slip reversibility in DO3-ordered Fe-Al single crystals by in situ experiments, Philos. Mag. A. 46 (1982), 357-378.

DOI: 10.1080/01418618208239564

[19] K. Otsuka, S. Miyazaki, Development of shape memory alloys, ISIJ Int. 29 (1989), 353-377.

DOI: 10.2355/isijinternational.29.353
