Evaluating Influences of Input Parameters on Surface Roughness in Sinking EDM Cylindrical Shaped Parts

Abstract:

The input parameters in the process of sinking Electrical Discharge Machining (EDM) are the essential enabling factors that need to be determined. In the present work, the influences of the EDM input parameters containing pulse on time (T_on), pulse off time (T_off), discharge current (IP), Server voltage (SV), work-piece diameter (d_w) on the surface roughness (SR) in sinking EDM cylindrical shaped part of 9CrSi material were investigated. Taguchi technique and analysis of variance (ANOVA) have been used to identify the weight of EDM factors on SR. The results show that the impact level of T_on, T_off, IP, SP, and d_w are 65.55%, 8.66%, 19.17%, 3.14%, and 0.76%, respectively. By analyzing the experimental results, optimum input parameters with the T_on of 6 ms, T_off of 30 ms, IP of 9A, SP of 3V, and d_w of 10mm have been determined, that allow getting the best surface roughness.

• Periodical: Materials Science Forum (Volume 1018)
• Pages: 85-90
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1018.85
• Online since: January 2021
• Authors: Tran Thi Hong, Nguyen Anh Tuan, Bui Thanh Danh, Le Hong Ky, Nguyen Hong Linh, Tran Ngoc Giang, Vu Ngoc Pi, Nguyen Manh Cuong*
• Keywords: Cylindrical Shaped Part, EDM, EDM Sinking, Surface Roughness, Taguchi Method

References

[1] Malhotra, P., et al., Experimental investigation and effects of process parameters on EDM of Al7075/SiC composite reinforced with magnesium particles. Materials Today: Proceedings, (2019).

DOI: 10.1016/j.matpr.2019.11.069

[2] Yue, X., Q. Li, and X. Yang, Influence of thermal stress on material removal of Cf_SiC composite in EDM. Ceramics International, (2019).

[3] Gugulothu, B., Optimization of process parameters on EDM of titanium alloy. Materials Today: Proceedings, (2019).

[4] Singh, N.K., et al., Predictive analysis of surface roughness in EDM using semi-empirical, ANN and ANFIS techniques: A comparative study. Materials Today: Proceedings, (2019).

DOI: 10.1016/j.matpr.2019.08.234

[5] Kumar, S.D., et al., Effect of EDM process parameters on material removal rate and surface roughness of metal matrix composites: A review. Materials Today: Proceedings, (2019).

DOI: 10.1016/j.matpr.2019.06.725

[6] Alagarsamy, S., et al., Optimization of electric discharge machining parameters on surface roughness for Al/ZrO2 composite through response surface methodology. Materials Today: Proceedings, (2020).

DOI: 10.1016/j.matpr.2020.01.344

[7] Torres, A., C. Luis, and I. Puertas, EDM machinability and surface roughness analysis of TiB2 using copper electrodes. Journal of Alloys and Compounds, 2017. 690: pp.337-347.

DOI: 10.1016/j.jallcom.2016.08.110

[8] Tran, T.H., et al. Analysis of Effects of Machining Parameters on Surface Roughness in Electrical Discharge Machining Tablet Shape Punches Using Taguchi Method. in Materials Science Forum. 2020. Trans Tech Publ.

DOI: 10.4028/www.scientific.net/msf.977.12
