Isothermal Oxidation Behavior of FGH720Li Superalloy at Service Temperatures

Abstract:

The oxidation behavior of FGH720Li(P/M Udimet720Li) superalloy was investigated under static atmosphere in temperature ranging from 600°C to 730°C. The oxidation kinetics, composition and morphology of the oxidation layers were characterized by means of isothermal oxidation tests, X-ray diffraction(XRD), scanning electron microscopy（SEM）and energy dispersive X-ray spectroscopy(EDS). The results showed that the oxidation kinetics curves of FGH720Li superalloy followed the parabolic law. The results of cross-sectional morphology and elemental distribution indicated that the oxidation layer could be divided into three parts：porous Cr₂O₃ outer layer, dense Cr₂O₃ medium layer and oxidation affected zone with nail-like Al₂O₃ inner layer. The oxidation process was primarily controlled by the diffusion of chromium and oxygen through the oxide scale.

• Periodical: Materials Science Forum (Volume 1035)
• Pages: 96-101
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1035.96
• Online since: June 2021
• Authors: Yue Tang*, Zi Chao Peng, Xu Qing Wang, Guo Jun Ma, Dan Wu
• Keywords: Diffusion, FGH720Li Superalloy, Isothermal Oxidation, Oxidation Layer

References

[1] Fecht F H. Ni-based superalloys for turbine discs. JOM Journal of the Minerals, Metals & Materials Society, 1999.14-17.

DOI: 10.1007/s11837-999-0005-y

[2] Reed R C, Jackson M P, Na Y S. Characterization and modeling of the precipitation of the sigma phase in UDIMET 720 and UDIMET 720Li. Metallurgical and Materials Transactions A, (1999).

DOI: 10.1007/s11661-999-0044-6

[3] Gopinath K, Gogia A K, Kamat SV, et al. Tensile Properties of Ni-Based Superalloy 720Li: Temperature and Strain Rate Effects. Metallurgical and Materials Transactions A, 2008, 39(10): 2340-2350.

DOI: 10.1007/s11661-008-9585-3

[4] Birbilis N , Buchheit R G . Measurement and Discussion of Low-Temperature Hot Corrosion Damage Accumulation upon Nickel-Based Superalloy Rene 104. Metallurgical and Materials Transactions A, 2008, 39(13):3224-3232.

DOI: 10.1007/s11661-008-9662-7

[5] Gibson G J , Perkins K M , Gray S , et al. Influence of shot peening on high-temperature corrosion and corrosion-fatigue of nickel based superalloy 720Li. High Temperature Technology, 2016, 33(3):225-233.

DOI: 10.1080/09603409.2016.1161945

[6] Lupinc V, Maldini M . CREEP BEHAVIOR MODELING OF UDIMET 720Li SUPERALLOY. Acta Metallurgica Sinica (English Letters), 2005(01):65-73.

[7] Hindam H, Whittle D P . Microstructure, adhesion and growth kinetics of protective scales on metals and alloys. Oxidation of Metals, 1982, 18(5-6):245-284.

DOI: 10.1007/bf00656571

[8] Liu C. T, Ma J , Sun X F . Oxidation behavior of a single-crystal Ni-base superalloy between 900 and 1000 °C in air. Journal of Alloys & Compounds, 2010, 491(1-2):522-526.

DOI: 10.1016/j.jallcom.2009.10.261

[9] Liu F. J , Zhang M C , Dong J X , et al. HIGH-TEMPERATURE OXIDATION OF FGH96 P/M SUPERALLOY. Acta Metallurgica Sinica, 2007(02):28-36.

DOI: 10.1016/s1006-7191(07)60014-3

[10] Zheng L, Zhang M, Dong J. Oxidation behavior and mechanism of powder metallurgy Rene95 nickel based superalloy between 800 and 1000 °C. Applied Surface, 2010, 256(24):7510-7515.

DOI: 10.1016/j.apsusc.2010.05.098

[11] Peng Z. C, Ma G J , Wang X Q , et al. Study of Isothermal Oxidation Behavior of FGH91 Superalloy. Materials ence Forum, 2015, 816:628-633.

DOI: 10.4028/www.scientific.net/msf.816.628

[12] Richard E. Sonntag, Fundamentals of Thermodynamics, 8th ed, Wiley, University of Michigan, (2004).
