Numerical and Experimental Studies on Hydro-Forming of a Thin Metallic Disc

Abstract:

This paper deals with the hydro-forming of a flat thin metallic disc to achieve a forward domed disc which will be subsequently adopted to manufacture a rupture disc. The plastic deformation induced by the hydraulic energy is numerically simulated through an isotropic hardening plasticity model using a non-linear explicit finite element analysis (FEA). The variation in disc’s central deformation, thickness, equivalent plastic stress and equivalent plastic strain with respect to the applied hydraulic pressure are determined from FEA simulations. The hydro-forming setup is then designed and manufactured, and the metallic disc is experimented under hydro-forming process. The reduction in thickness due to stretching of the thin disc is evaluated from experiment and simulation and a close agreement is found. This research attempt helped in finalizing the hydro-forming fluid pressure, the feasibility and the accuracy of practically achieving the desired geometry of the metallic disc. The near-fixidity effects on abrupt variation in sheet thickness and plastic strain are well captured through simulations which are very difficult to be studied through hydro-forming experiments.

• Periodical: Materials Science Forum (Volume 1048)
• Pages: 270-278
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1048.270
• Online since: January 2022
• Authors: Kanakadandi Gopinath, Vijayabaskar Narayanamurthy*, Yendluri Venkata Daseswara Rao
• Keywords: Experiment, Explicit FEA, Hydroforming, Metallic Disc, Thickness Reduction

References

[1] K. Siegert, S. Wagner, Hydroforming sheet metal forming components, in: Muammer Koҁ (Ed.) Hydro-forming for Advanced Manufacturing, Woodhead Publishing, Cambridge, 2008, p.216–237.

DOI: 10.1533/9781845694418.2.216

[2] E. Ceretti, A. Fiorentino, C. Giardini, Hydroforming (Sheets and Tubes), in: L. Laperrière, G. Reinhart (Eds.) CIRP Encyclopedia of Production Engineering, Springer, Heidelberg, 2014, p.674–682.

DOI: 10.1007/978-3-642-20617-7_6506

[3] Z. Marciniak Z, J.L. Duncan, S.J. Hu, Hydroforming, in: Z. Marciniak Z, J.L. Duncan, S.J. Hu (Eds.), Mechanics of Sheet Metal Forming, second ed., Butterworth-Heinmann, Oxford, 2002, p.152–163.

DOI: 10.1016/b978-075065300-8/50014-5

[4] S.H. Zhang, Z.R. Wang, Y. Xu, Z.T. Wang, L.X. Zhou, Recent developments in sheet hydro-forming technology, J. Mater. Process. Technol. 151 (2004) 237–241.

[5] C. Bell, J. Corney, N. Zuelli, D. Savings, A state of the art review of hydro-forming technology Int. J. Mater. Form. 13(2020) 789–828.

DOI: 10.1007/s12289-019-01507-1

[6] A. Cherouat, M. Ayadi, N. Mezghani, F. Slimani, Experimental and finite element modelling of thin sheet hydro-forming processes, Int. J. Mater. Form. 1(2008) 313–316.

DOI: 10.1007/s12289-008-0339-y

[7] M.H. Parsa, P. Darbandi, Experimental and numerical analyses of sheet hydro-forming process for production of an automobile body part, J. Mater. Process. Technol. 198 (2008) 381– 90.

DOI: 10.1016/j.jmatprotec.2007.07.023

[8] L.P. Lei, J. Kim, B.S. Kang, Analysis and design of hydro-forming process for automobile rear axle housing by FEM, Int. J. Mach. Tools Manuf. 40 (2000) 1691–1708.

DOI: 10.1016/s0890-6955(00)00031-6

[9] B.S. Kang,B M Son, J. Kim, A comparative study of stamping and hydro-forming processes for an automobile fuel tank using FEM, Int. J. Mach. Tools Manuf. 44 (2004) 87–94.

DOI: 10.1016/j.ijmachtools.2003.08.009

[10] M. Zampaloni, N. Abedrabbo, F. Pourboghrat, Experimental and numerical study of stamp hydro-forming of sheet metals, Int. J. Mech. Sci. 45 (2003) 1815–1848.

DOI: 10.1016/j.ijmecsci.2003.11.006

[11] S.H. Zhang, J. Danckert, Development of hydro-mechanical deep drawing, J. Mater. Process. Technol. 83 (1998) 14–25.

[12] S.H. Zhang, Developments in hydro-forming, J. Mater. Process. Technol. 91 (1999) 236–244.

[13] A. Kandil, An experimental study of hydro-forming deep drawing, J. Mater. Process. Technol. 134 (2003) 70–80.

[14] S. Nakamura, H. Sugiura, H. Onoe, K. Ikemoto, Hydromechanical drawing of automotive parts, J. Mater. Process. Tech. 46 (1994) 491–503.

DOI: 10.1016/0924-0136(94)90129-5

[15] L.H. Lang, Z.R. Wang, D.C. Kang, S.J. Yuan, S.H. Zhang, J. Danckert, K.B. Nielsen, Hydro-forming highlights: Sheet hydro-forming and tube hydro-forming, J. of Mater. Process. Tech. 151 (2004) 165–177.

DOI: 10.1016/j.jmatprotec.2004.04.032

[16] S.H. Zhang, L.X. Zhou, Z.T. Wang, Y. Xu, Technology of sheet hydro-forming with a movable female die, Int. J. Mach. Tools Manuf. 43 (2003) 781–785.

[17] C.L. Rao, V. Narayanamurthy, K.R.Y. Simha, Computational Impact Mechanics, in: Applied Impact Mechanics, John Wiley & Sons Ltd., United Kingdom, 2016, p.171–219.

[18] IS 277:2003, Galvanized steel sheets (plain and corrugated)-specification (Sixth revision), Indian Standard.

[19] ASTM E8/E 8M-08, Standard Test Methods for Tension Testing of Metallic Materials, American Society for Testing Materials, (2008).

[20] ABAQUS Analysis User's Manual, ABAQUS Version 2017, Dassault Systems, 2017, Dassult Systems, Providence, RI, USA, (2015).

[21] 817M40; BS 970-3:1991, Specification for wrought steel for mechanical and allied engineering purposes, part 3: Bright bars for general engineering purpose, British Standard.

DOI: 10.3403/00257223u
