Microwave Sintering Modification of 85M₇Z₃CLT Microwave Dielectric Ceramics

Abstract:

The 0.85(Mg_0.7Zn_0.3)TiO₃-0.15(Ca_0.61La_0.26)TiO₃(referred to as 85M₇Z₃CLT) ceramics were fabricated by microwave sintering(MWS) and conventional sintering(CS) techniques. The effects of MWS and CS on the sintering property, crystal phase structure and dielectric properties of 85M₇Z₃CLT were discussed. Compared with CS, MWS had a short sintering period and a high volume density. The results indicated that the phase composition of 85M₇Z₃CLT ceramics were not changed after MWS, with (Mg_0.7Zn_0.3)TiO₃ and (Ca_0.61La_0.26)TiO₃ structure as the main crystal phase were also obtained by MWS. However, the grain growth was significantly inhibited due to the rapid sintering speed of MWS, which resulted in a fine, uniform microstructure. Furthermore, microwave-sintered ceramics had excellent dielectric properties due to the miscellaneous phase (Mg_0.7Zn_0.3)Ti₂O₅ being suppressed. As a result, excellent dielectric properties of 27.11 for ε_r, 103,500GHz for Q·f and +2ppm/°C for τ_f were obtained by microwave sintering at 1275°C for 20 min. Therefore, the ceramic quality factor was increased by 22% compared with the conventional sintering.Key words: microwave technique; (Mg,Zn)TiO₃; dielectric ceramics

• Periodical: Materials Science Forum (Volume 1147)
• Pages: 13-19
• DOI: https://doi.org/10.4028/p-oM3LbF
• Online since: March 2025
• Authors: Li Zhao*, Guang Yu Li, Jia Feng Liu, Xun Fei Cai, Qi Hu, Yu Ye Hu, Ya Long Jiang
• Keywords: (Mg,Zn)TiO₃, Dielectric Ceramics, Dielectric Property, Microwave Dielectric Ceramics, Microwave Sintering

References

[1] Zhao L, Shen C Y, Qiu T. Studies on the (1-x)(Mg0.7Zn0.3)TiO3-x(Ca0.61La0.26)TiO3 microwave dielectric ceramics. Journal of Inorganic Material, 26(2): 219~224 (2011).

[2] Liu, J, Liang, B L, Zhang, J J, et al. Research Progress on Microwave Dielectric Ceramics Prepared via Microwave Sintering. Journal of the American Ceramic Society, 36(3): 37–42 (2022).

[3] Demirskyi D, Cheng J, Agrawal D, et al. Densification and grain growth during microwave sintering of titanium diboride. Scripta Materialia, 69(8): 610–613 (2013).

DOI: 10.1016/j.scriptamat.2013.07.012

[4] Cai W, Fu C, Hu W, et al. Effects of microwave sintering power on microstructure, dielectric, ferroelectric and magnetic properties of bismuth ferrite ceramics. Journal of Alloys and Compounds, 554: 64–71 (2013).

DOI: 10.1016/j.jallcom.2012.11.154

[5] Tan Y, Shen C S, Qiu T. Preliminary study on microwave sintered Ba6-3xSm8+2xTi18O54 ceramic materials. Piezoelectrics and acousto-optical, 32(2): 301-303 (2010).

[6] Li J M, Qiu T. Microwave sintering of Ca0.6La0.2667TiO3 microwave dielectric ceramics. International Journal of Minerals, Metallurgy and Materials,3(19): 245-247 (2012).

DOI: 10.1007/s12613-012-0546-x

[7] Mohammadi, S, Shokrollahi, H, Bashi, MH. Effects of Gd on the magnetic, electric and structural properties of BiFeO3 nanstructures synthesized by co-precipitation followed by microwave sintering. Journal of magnetism and magnetic materials, 375: 38-42 (2015).

DOI: 10.1016/j.jmmm.2014.09.050

[8] Yu J, Shen C S. Study on microwave sintering of ceramics in 0.92MgAl2O4-0.08(Ca0.8Sr0.2)TiO3 medium. Electronic components and materials, 34(5): 1-4 (2015).

[9] ZHAO L, SHEN C Y, QIU T. Studies on the (1-x)(Mg0.7Zn0.3)TiO3-x(Ca0.61La0.26)TiO3 microwave dielectric ceramics[J]. Journal of Inorganic Material, 26(2): 219~224(2011).

[10] Liou Y C, Yang S L. Calcium-doped MgTiO3-MgTi2O5 ceramics prepared using a reaction-sintering process. Materials Science and Engineering, 142(2/3): 116−120(2007).

DOI: 10.1016/j.mseb.2007.06.027

[11] Gogoi P, Singh LR, Pamu D. Characterization of Zn doped MgTiO3 ceramics: an approach for RF capacitor applications. Journal of Materials Science-Materials in Electronics, 28(16): 11712-11721(2017).

DOI: 10.1007/s10854-017-6975-6

[12] Geng H.X., Mei A., Dong C., et al. Investigation of structure and electrical properties of Li0.5La0.5TiO3 ceramics via microwave sintering. J. Alloys Compd. , 481(2): 555 (2009).

DOI: 10.1016/j.jallcom.2009.03.038

[13] Huang C L, Li G J, Wang J J. Microwave dielectric properties of (1-x)(Mg0.95Zn0.05)TiO3-x(Na0.5La0.5)TiO3 ceramic system[J]. J. Alloys. Compd., 472: 497-501 (2009).

DOI: 10.1016/j.jallcom.2008.05.007

[14] Li LX, Li S, Tian T, et al. Microwave dielectric properties of (1-x)MgTiO3-x(Ca0.6Na0.2Sm0.2)TiO3 ceramic system. Journal of Materials Science-Materials in Electronics, 27(2): 1286-1292(2016).

DOI: 10.1007/s10854-015-3887-1

[15] Cho WW, Kakimoto K, Ohsato H. High-Q microwave dielectric SrTiO3-doped MgTiO3 materials with near-zero temperature coefficient of resonant frequency. Japanese Journal of Applied Physics Part 1-Regular Papers Short Notes & Review Papers, 43(9A): 6221-6224(2004).

DOI: 10.1143/jjap.43.6221

[16] Li L, Ye J, Zhang S. Influence of CaTiO3 modification on microstructures and microwave dielectric properties of Mg0.97Zn0.03TiO3 ceramics doped with 0.5mol% Zn-excess [J]. Journal of Alloys and Compounds, 2015, 648: 184-189.

DOI: 10.1016/j.jallcom.2015.06.210

[17] Gogoi P, Singh LR, Pamu D. Characterization of Zn doped MgTiO3ceramics: an approach for RF capacitor applications[J]. Journal of materials science: materials in electronics, 2017, 28: 11712-11721.

DOI: 10.1007/s10854-017-6975-6

[18] Yu Y, Wang YJ, Guo WJ, et al. Grain size engineered 0.95MgTiO3-0.05CaTiO3 ceramics with excellent microwave dielectric properties and prominent mechanical perfor-mance[J]. Journal of the American Ceramic Society, 2022, 105(1): 299-307.

DOI: 10.1111/jace.18045

[19] Yuan S F, Gan L, Ning F F, et al. High-Q×f 0.95MgTiO3–0.05CaTiO3 microwave dielectric ceramics with the addition of Li F Sintered at medium temperatures[J]. Ceramics International,2018, 44(16):20566-20569.

DOI: 10.1016/j.ceramint.2018.07.202

[20] Rabha S, Dobbidi P. Structural electrical properties and stability in microwave dielectric properties of (1-x) MgTiO3-x SrTiO3 composite ceramics[J]. Journal of Alloys and Compounds, 2021, 872: 159726.

DOI: 10.1016/j.jallcom.2021.159726
