Cleaner Melt Transfer of Recycled Aluminium Alloys: Simulation-Guided Launder Baffle Design for Aerospace-Grade Structural Castings

Abstract:

Cleaner melt transfer is critical to the broader use of recycled aluminium alloys in high-end structural casting applications, where oxide bifilms and intermetallic inclusions, such as Fe-containing intermetallics, can significantly affect the casting's mechanical properties. In counter-gravity low- and high-pressure casting, the launder system must not only promote the sedimentation of inclusions but also deliver a stable, cleaner melt to the crucible. Prior research showed that 15° double baffles in the mid-section of the sedimentation launder at a flow rate of 100 kg·h^-1 provide high efficiency. The present work investigates the influence of baffle design at the launder-crucible interface, where the melt enters the crucible before casting. Fluid dynamic simulations were carried out at a 100 kg·h^-1 flow rate for three inlet configurations: (i) full baffle; (ii) lifted baffle; and (iii) split baffle. Inclusions of various densities and diameters were tracked. Results indicate that the full baffle, while beneficial as a benchmark and efficient, is impractical because it generates fresh oxide surfaces. The lifted baffle provided the most effective reduction in inclusions, like the full baffle setup, enhancing sedimentation and suppressing entrainment, while the split baffle showed intermediate behaviour. Moreover, the lifted configuration promoted centrifugal flow (at lower velocities, it still made a partial contribution) within the crucible, directing inclusions towards the crucible wall and the stagnation-velocity zone, and enabling the crucible itself to act as a final sedimentation stage before the counter-gravity pump extracts the melt. These results demonstrate that combining mid-launder optimisation with crucible inlet baffle design enables cleaner, more automated melt delivery, thereby strengthening the use of recycled aluminium alloys in structural casting applications.

• Periodical: Materials Science Forum (Volume 1188)
• Pages: 95-105
• Online since: April 2026
• Authors: Tharmalingam Sivarupan*, Arul Mozhi Varman Jayaraman Palanivel, Konstantinos Georgarakis, John Forde, Ben Shaw, Konstantinos Salonitis, Mark Jolly
• Keywords: Aerospace Castings, Aluminum Alloy, Baffle, HPC, Impurity Elements, Sedimentation, Simulation, Sustainability

References

[1] Campbell J. The consolidation of metals: the origin of bifilms. Journal of Materials Science 2016;51.

DOI: 10.1007/s10853-015-9399-9

[2] Dispinar D, Campbell J. Use of bifilm index as an assessment of liquid metal quality. International Journal of Cast Metals Research 2006; 19. https://doi.org/10.1179/ 136404606225023300.

DOI: 10.1179/136404606225023300

[3] El-Sayed MA. The behaviour of bifilm defects in cast Al-7Si-Mg alloy. PLoS One 2016;11.

DOI: 10.1371/journal.pone.0160633

[4] Zhang L, Taniguchi S, Cai K. Fluid flow and inclusion removal in continuous casting tundish. Metallurgica and Materials Transactions B 2000;31:253–66.

DOI: 10.1007/s11663-000-0044-9

[5] Fang Q, Zhang H, Luo R, Liu C, Wang Y, Ni H. Optimisation of flow, heat transfer and inclusion removal behaviours in an odd multistrand bloom casting tundish. Journal of Materials Research and Technology 2020;9.

DOI: 10.1016/j.jmrt.2019.10.064

[6] He Z, Zhou K, Liu S, Xiong W, Li B. Numerical modelling of the fluid flow in continuous casting tundish with different control devices. Abstract and Applied Analysis 2013;2013.

DOI: 10.1155/2013/984894

[7] Liu G, Ren Y, Ma W, Morita K, Lei Y, Zhan S, et al. Recent advances and future trends of aluminium alloy melt purification: A review. Journal of Materials Research and Technology 2024;28:4647–62.

DOI: 10.1016/J.JMRT.2024.01.024

[8] TU Delf Open Courseware. Sedimentation; WATER TREATMENT. n.d.

[9] T Sivarupan et al. Baffle-Based Sedimentation Strategies for Inclusions in Launders of Aerospace Aluminium Casting: A Sustainable Approach. 2026 TMS Annual Meeting & Exhibition, 2026.

DOI: 10.1007/978-3-032-13832-3_162

[10] Griffiths WD, Beshay Y, Parker DJ, Fan X, Hausard M. The application of positron emission particle tracking (PEPT) to study the movement of inclusions in shape castings. Shape Casting: 3rd International Symposium 2009.

DOI: 10.1179/174328409x405643

[11] Burnard DJ. Positron Emission Particle tracking of inclusions in cast liquid metals. 2015.

[12] Salonitis K, Jolly MR, Zeng B, Mehrabi H. Improvements in energy consumption and environmental impact by novel single-shot melting process for casting. Journal of Cleaner Production 2016;137:1532–42. https://doi.org/.

DOI: 10.1016/j.jclepro.2016.06.165

[13] Sivarupan T, Palanivel AMVJ, Georgarakis K, Forde J, Rawding J, Shaw B, et al. Sedimentation of Inclusions in Melts of Aerospace Structural Aluminium Alloy Castings: A Sustainable Approach. In: Edwards L, editor. Light Metals 2025, Cham: Springer Nature Switzerland; 2025, p.1172–9.

DOI: 10.1007/978-3-031-80676-6_146

[14] Campbell J. Complete Casting Handbook: Metal Casting Processes, Metallurgy, Techniques and Design: Second Edition. 2015.

DOI: 10.1016/C2014-0-01548-1
