Characteristics of Electrical Discharge Pulse Sound for Hammering Test

Abstract:

In this study, the possibility of electrical discharge pulse sound for new inspection technologies instead of hammering test was investigated. Electrical discharge pulse sound was applied for hammering sound and sensor by using sound detection was applied for the optical fiber vibration sensor. Elastic wave was detected by optical fiber vibration sensor during electrical discharge. The plate thickness was changed from 0.5mm to 10mm. On the assumption that generation factor of elastic wave was only depending on a force, numerical analysis by using the finite element method (FEM) was adapted. The numerical analysis result using the FEM and the experimental result along with the electrical discharge were compared. The plate thickness was estimated by comparing with experimental signal and simulation one. It was found that plate thickness was able to estimate from comparing with experimental signal and simulation one. Moreover, a quasi-defect was created the plate by comparing with experimental results and simulation one. It was found that the defect shape was able to estimate by comparing with experimental results and simulation one.

• Periodical: Materials Science Forum (Volumes 561-565)
• Pages: 2249-2252
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.561-565.2249
• Online since: October 2007
• Authors: Yoshiaki Akematsu, Kazuro Kageyama, Naotake Mohri, Hideaki Murayama, Makoto Kanai
• Keywords: Electrical Discharge Pulse Sound, Finite Element Model (FEM), Hammering Test, Optical Fiber Vibration Sensor

References

[1] Kazuro Kageyama et al., : Acoustic emission monitoring of a reinforced concreate structure by applying new fiber-optic sensors, Smart Materials and Structures, 14, 2005, S52-59.

DOI: 10.1088/0964-1726/14/3/007

[2] Kazuro Kageyama et al.,: Doppler Effect in Flexible and Expandable Light-Waveguide and Development of New Fiber-Optic Vibration/Acoustic Sensor，IEEE Journal of Light wave Technology，Vol. 24, No. 4, 2006, pp.1768-1775.

DOI: 10.1109/jlt.2005.863331

[3] Kazuro Kageyama et al., : Acoustic Emission Monitoring by Using Fiber-optic Strain Rate (DEFEW) Sensor, JSNDI acoustic emission special workshop, No. 123, pp.1-10, (2005).

[4] Yoshiaki Akematsu et al.,: Measurmrnt of Deformation Behavior near Discharge Point by using Optical Fiber Sensor, J. J. Soc. Precision Engineering, vol. 72(6), 804-808, (2006).

DOI: 10.2493/jspe.72.804

[5] Yoshiaki Akematsu et al.,: Effect of Plate Thickness on Acoustic Emission Wave Propagation during Single Pulse Discharge, The 18th International Acoustic Emission Symposium (IAES-18), July 25-27, 2006, pp.27-32.

DOI: 10.1364/ofs.2006.tuc4

[6] Yoshiaki Akematsu et al.,: Effect of gap region medium on acoustic emission wave by single pulse discharge, 18th International Conference on Optical Fiber Sensors, Oct 22-27, (2006).

DOI: 10.1364/ofs.2006.tuc4

[7] Yoshiaki Akematsu et al.,: Detection of Acoustic Emission Wave by Using Optical Fiber Sensor during Single Pulse Discharge, SPIE 11th Annual Symposium Nondestructive Evaluation for Health Monitoring and Diagnostics, Vol. 6179, 61790O, February 26-May 2, (2006).

DOI: 10.1117/12.657550
